Introduction

One of the hardest concepts to comprehend in image processing is Fourier Transforms. There are two reasons for this. First, it is mathematically advanced and second, the resulting images, which do not resemble the original image, are hard to interpret.

Nevertheless, utilizing Fourier Transforms can provide new ways to do familiar processing such as enhancing brightness and contrast, blurring, sharpening and noise removal. But it can also provide new capabilities that one cannot do in the normal image domain. These include deconvolution (also known as deblurring) of typical camera distortions such as motion blur and lens defocus and image matching using normalized cross correlation.

It is the goal of this page to try to explain the background and simplified mathematics of the Fourier Transform and to give examples of the processing that one can do by using the Fourier Transform.

If you find this too much, you can skip it and simply focus on the properties and examples, starting with FFT/IFT In ImageMagick

For those interested, another nice simple discussion, including analogies to optics, can be found at An Intuitive Explanation of Fourier Theory.

Other introductory discussions include Introduction To Fourier Transforms For Image Processing, Fourier Transforms , DFT and FFT, and Image Filtering in the Frequency Domain.

For the more mathematically inclined, see: Fourier Transform, and 2D Fourier Transforms.

Other mathematical references include Wikipedia pages on Fourier Transform, Discrete Fourier Transform and Fast Fourier Transform as well as Complex Numbers.


The Fourier Transform

An image normally consists of an array of 'pixels' each of which are defined by a set of values: red, green, blue and sometimes transparency as well. But for our purposes here we will ignore transparency. Thus each of the red, green and blue 'channels' contain a set of 'intensity' or 'grayscale' values.

This is known as a raster image 'in the spatial domain'. This is just a fancy way of saying, the image is defined by the 'intensity values' it has at each 'location' or 'position in space'.

But an image can also be represented in another way, known as the image's 'frequency domain'. In this domain, each image channel is represented in terms of sinusoidal waves.

In such a 'frequency domain', each channel has 'amplitude' values that are stored in locations based not on X,Y 'spatial' coordinates, but on X,Y 'frequencies'. Since this is a digital representation, the frequencies are multiples of a 'smallest' or unit frequency and the pixel coordinates represent the indices or integer multiples of this unit frequency.

But how can an image be represented as a 'wave'?

Images are Waves

Well if we take a single row or column of pixel from any image, and graph it (generated using "gnuplot" using the script "im_profile"), you will find that it looks rather like a wave.

	convert holocaust_tn.gif -colorspace gray \
		-gravity center -crop 0x1+0+0 miff:- |\
		im_profile -s - image_profile.gif
[IM Output] ==> [IM Output]

If the fluctuations were more regular in spacing and amplitude, you would get something more like a wave pattern, such as...

	convert -size 20x150 gradient: -rotate 90 \
		-function sinusoid 3.5,0,.4   wave.gif

	im_profile -s wave.gif wave_profile.gif
[IM Output] ==> [IM Output]

However while this regular wave pattern is vaguely similar to the image profile shown above, it is too regular.

However if you were to add more waves together you can make a pattern that is even closer to the one from the image.

	convert -size 1x150 gradient: -rotate 90 \
		-function sinusoid 3.5,0,.25,.25 wave_1.png
	convert -size 1x150 gradient: -rotate 90 \
		-function sinusoid 1.5,-90,.13,.15 wave_2.png
	convert -size 1x150 gradient: -rotate 90 \
		-function sinusoid 0.6,-90,.07,.1 wave_3.png

	convert wave_1.png wave_2.png wave_3.png \
		-background black -compose plus -flatten  added_waves.png
[IM Output]  + [IM Output]  + [IM Output] ==> [IM Output]

See also Adding Biased Gradients for a alternative example to the above.

This 'wave superposition' (addition of waves) is much closer, but still does not exactly match the image pattern. However, you can continue in this manner, adding more waves and adjusting them, so the resulting composite wave gets closer and closer to the actual profile of the original image. Eventually by adding enough waves you can exactly reproduce the original profile of the image.

This was the discovery made by the mathematician Joseph Fourier. A modern interpretation of which states that "any well-behaved function can be represented by a superposition of sinusoidal waves".

In other words by adding together a sufficient number of sine waves of just the right frequency and amplitude, you can reproduce any fluctuating pattern. Therefore, the 'frequency domain' representation is just another way to store and reproduce the 'spatial domain' image.

The 'Fourier Transform' is then the process of working out what 'waves' comprise an image, just as was done in the above example.

Sinusoidal Waves

The following is an image of 1D sinusoidal curve. It is a stationary wave in space, since it is not moving. that is to say it not a function of time.


	convert -size 20x150 gradient: -rotate 90 -evaluate sine 5 sine5_wave.gif

	im_profile -s sine5_wave.gif sine5_wave_profile.gif
[IM Output] ==> [IM Output]

The equation describing a stationary, spatial sinusoidal wave may be expressed as follows.

(1) [IM Output]

Here u is the intensity of the wave as a function of its position x. The amplitude, A, is half the height from peak to trough. The number of full up and down cycles is given by n, which is also called the harmonic index and N is the interval of the wave, namely, the width of the image. Thus, the frequency, f=n/N, is how rapidly it moves up and down. The distance from peak to peak, λ, is the wavelength. Also φ is the phase of the wave. If φ is set to zero, then we have a sine wave and if φ is set to π/2, then we have a cosine wave. The image and profile above correspond to a sine wave with 5 full up and down cycles. The following is the equivalent cosine wave with 5 cycles.


	convert -size 20x150 gradient: -rotate 90 -evaluate cosine 5 cosine5_wave.gif

	im_profile -s cosine5_wave.gif cosine5_wave_profile.gif
[IM Output] ==> [IM Output]

Notice the shift of the wave profile to the left by one quarter of the wavelength due to the phase difference of π/2. (A phase shift of 2*π or 360 degrees brings us right back to the original sine wave.)

So what are the limits on the frequency that one can produce in an image? Well, obviously an image channel that is a constant graylevel has zero frequency. This is called the DC frequency, which is a term that arises from electronics and means "direct current", since it only flows in one direction and does not oscillate back and forth. If one only considers full cycles, then the next frequency corresponds to 1 full cycle or n=1 and the frequency is f=1/N. This is called the fundamental frequency or first harmonic wave.


	convert -size 20x150 gradient: -rotate 90 -evaluate sine 1 sine1_wave.gif

	im_profile -s sine1_wave.gif sine1_wave_profile.gif
[IM Output] ==> [IM Output]

The next higher frequency will have n=2 and f=2/N and is called the second harmonic wave.


	convert -size 20x150 gradient: -rotate 90 -evaluate sine 2 sine2_wave.gif

	im_profile -s sine2_wave.gif sine2_wave_profile.gif
[IM Output] ==> [IM Output]

This continues until we reach the maximum number of full cycles that is allowed, which is n=N/2; that is there is a full cycle every 2 pixels. Therefore, the frequency is f=1/2. This frequency is called the Nyquist frequency.


	convert -size 20x1500 gradient: -rotate 90 -evaluate sine 75 \
		-scale 10% -contrast-stretch 0 sine75_wave.gif

	im_profile -s sine75_wave.gif sine75_wave_profile.gif
[IM Output] ==> [IM Output]

The extra large image and subsequent processing used in the above are only included to avoid aliasing artifacts that occur near or above the Nyquist frequency. If we do not avoid the aliasing, we then get the following, which is artificially tapered due to the aliasing.


	convert -size 20x150 gradient: -rotate 90 -evaluate sine 75 sine75_aliased_wave.gif

	im_profile -s sine75_aliased_wave.gif sine75_aliased_wave_profile.gif
[IM Output] ==> [IM Output]

It is stated without proof that any image pattern can be recreated by an appropriate combination of each sinusoidal wave between zero and the Nyquist frequency. An interesting demonstration is shown below and creates a step function pattern by combining (superposing) multiple sinusoidal harmonics. See Square Wave.

[IM Output]

The ripples or ringing effect, known as the Gibbs phenomenon, is due to the finite bandwidth of the sinusoidal waves. That is, only a finite number of harmonics were used.

Complex Number Sinusoidal Waves

The Fourier Transform is founded upon the concept of complex number sinusoidal waves. What this means is that the wave is made up of two sinusoidal components, one considered 'real' and the other considered 'imaginary', mathematically speaking.

So what is a complex number? A complex number is expressed as c = a + ib, where a is the real part, b is the imaginary part and i is a symbol that represents sqrt(-1). A complex number may be represented as vector diagrams as shown below. See Complex Numbers.
[IM Output] [IM Output]

In polar form, we have r, which is called the magnitude and is equal to sqrt(a^2 + b^2) or sqrt(RealPart^2 + ImaginaryPart^2) and φ, which is called the phase and is equal to arctan2(b,a) or arctan2(ImaginaryPart,RealPart).

So getting back, a complex sinusoidal wave is expressed using Euler's Formula as:

(2) [IM Output]

So it is just a combination of a cosine wave for the real component and a sine wave for the imaginary component, which is equivalent to a complex exponential, where e=2.71828 is the basis of the natural logarithm.


Discrete Fourier Transform Equation

So now we put all the above together and present the equations for the 1D Discrete Fourier Transform. Let the 1D image channel grayscale intensities be called g(x) and the Fourier Transform be called G(n). Then the forward discrete Fourier transform (DFT) is given by

(3) [IM Output]

where n=0,1,2...N-1. This says that the 1D Discrete Fourier Transform is a 1D array of N values, G(n), each of which is composed of an addition (superposition) of N complex sinusoidal waves whose amplitudes are the 1D image intensity values, g(x).

The inverse 1D Discrete Fourier Transform is given by a similar equation, namely,

(4) [IM Output]

where x=0,1,2...N-1. This says that each of the N image values at g(x) are just an addition (superposition) of all N possible frequencies (or harmonics), given by f=n/N, of complex sinusoidal waves whose amplitudes are the G(n) values.

We note that these two equations are very similar structurally to each other. There are two main differences. First, in the forward transform, the exponential term has a negative sign and in the inverse transform, it has a positive sign. Second, the forward transform is divided by N. This is just one convention of several. In some approaches, neither expression is divided by N. This is the unnormalized representation. In other representations, one or the other of the forward or inverse equations are divided by N. And in other representation, the normalization is symmetric with both equations divided by the square root of N. The reason for the factor of N is to preserve the mean squared magnitude (average signal) so that it is the same in both the spatial and frequency domains. Mathematical details can be found at Scaling.

For those interested, the following set of 5 links goes through the process of calculating a DFT for a 4-point image of a simple step function.

For a 2D image, these equations become

(5) [IM Output]

(6) [IM Output]

Thus the result of applying the 2D Discrete Fourier Transform on an image channel of size NxM will be a complex image of size NxM, i.e. coordinates ranging horizontally from n=0,1,2...N and vertically from m=0,1,2...M. The intensity values at these coordinates are called the Fourier Coefficients, G(n,m). They represent the strengths of each corresponding image frequency, fx=n/N and fy=m/M. However, as the transform is assumed to be periodic, the zero frequency location, called the DC point, is usually repositioned at coordinates (N/2,M/2) and thus we get negative frequencies on the left and top side of this point in the transform image. One reason for doing the shift is so that the most important (strongest) Fourier Coefficients will be in the middle and therefore easily visible.


FFT/IFT In ImageMagick

Imagemagick's implementation of FFT is based upon the open source FFTW code. Therefore, before one can do FFT operations, one must install the FFTW delegate library and then reinstall Imagemagick from source.

Note that there are several variations on normalization of the FFT and IFT.
  1. FFT Normalization: multiply the forward transform by 1/(N*M) and 1 for the inverse transform
  2. IFT Normalization: multiply the inverse transform by 1/(N*M) and 1 for the forward transform
  3. Equal Normalization: multiply both by 1/sqrt(N*M)
  4. No Normalization (un-normalized): multiply both by 1
The most common and original normalization is 2), for which the DC point (center and largest value of) the magnitude image is the sum of all the values in the input image. It also permits zero padding with no consequences. The next is 1), for which the DC point of the magnitude is the average value of the input image. The disadvantage is that zero padding must be compensated by un-normalization by multiplying by a factor of N*M. ImageMagick has chosen to use version 1) primarily because it permits the FFT magnitude to be save in non-HDRI mode without overflowing and clamping. However, there is now a -define fourier:normalize=inverse, so that one may switch IM to use the more common normalization. This becomes important when doing normalized cross correlation to avoid extra normalization compensation factors. The advantage of 3) and 4) is that they are symmetric. The disadvantage of 4) is that a round trip FFT followed by the IFT would increase the brightness of the result by a factor of N*M. The raw FFTW code produces an un-normalized FFT and IFT per version 4). Therefore, FFT normalization is added in the Imagemagick code.

In ImageMagick's initial implementation, as of version 6.5.4-3, any non-square image or one with an odd dimension will be padded automatically to be square at the maximum of the image width (N) or height (M) and to have even dimensions prior to applying the Forward Fourier Transform. The consequence of this is that after applying the Inverse Fourier Transform, such an image will need to be cropped back to its original dimensions.

NOTE: As of IM 6.6.0-9, Windows users can now use Fourier Transform functions in ImageMagick. An update was found and corrected thanks to user el_supremo to substitute for a missing complex.h library on Windows. See the following compile notes for help.

As the Fourier Transform is composed of complex numbers, the result of the transform cannot be visualized directly. Therefore, the complex transform is separated into two component images in one of two forms.

More commonly, the two components that are created are the magnitude and phase representations of the complex numbers. The advantage of this is that both contain only non-negative values. The magnitude, by definition, is always non-negative. However, the phase normally ranges from -π to +π. However, it is usual to shift it while doing the forward transform to the range 0 to 2π and then shift it back when doing the inverse transform. As the phase has a known range, it is also scaled to span the fully dynamic range 0 to quantumrange. The magnitude has no fixed range of values. However, one important feature is that the value at the DC or zero frequency position will be the average graylevel value of that image channel. Typically this is the largest value in the magnitude component. Usually all the other values in the magnitude image will be smaller. Consequently, the magnitude image generally will be dark or even totally black to the naked eye. Scaling the magnitude and applying a log transform of its intensity values usually will be needed to bring out any visual detail. The resulting log transformed image is called the 'spectrum'. But, note that the magnitude and not the spectrum should be used for the inverse transform. The magnitude and phase components are generated in ImageMagick using the -fft option. To transform back from magnitude and phase components, use the -ift option. One other note of caution is to use image formats for the output of the forward transform that do not restrict colors and do not compress the image. Thus it is recommended that one use either MIFF, TIF, PFM, EXR or PNG.

For those image formats, such as MIFF, TIF, PFM, MNG and EXR, that support multiple frames, the output will be a two-frame image. For image formats such as PNG that do not allow multiple frames, two images will be produced. If one wants to force two images as outputs for multi-frame formats, one can include the +adjoin option in the command line.

When using magnitude and phase components, that is -fft and -ift, ImageMagick may be hdri-enabled for higher precision, but that is not a requirement. However, Q8 non-hdri does not carry enough precision. Therefore, one will need to use quantum level compilations of ImageMagick of Q16 or Q32 non-hdri or any quantum level including Q8 with hdri enabled. The following examples using -fft and -ift to utilize magnitude and phase components were all done using the default, non-hdri, Q16 implementation.

Alternately, the two components that can be created are the real and imaginary representations of complex numbers. However, as these can contain negative values, ImageMagick must be compiled with hdri enabled. This permits image formats such as MIFF, TIF and PFM to preserve the negative and fractional values without clipping or truncating them to integers. The real and imaginary components are generated in ImageMagick using the +fft option. To transform back from real and imaginary components, use the +ift option.

Any examples done with real and imaginary components, that is with +fft and +ift, were all done using the hdri-enabled, Q16 implementation. This includes all of the advanced examples further down that demonstrate motion blurring, lens defocus and their corresponding deblurring, cepstrum and normalized cross correlation were all done using Q16 hdri compilation of IM with real and imaginary components generated from +fft and +ift.

For more information about using HDRI-enabled ImageMagick, see --enable-hdri in Advanced Unix Installation and High Dynamic Range

Now, lets simply try a Fourier Transform round trip on the Lena image. That is, we simply do the forward transform and immediately apply the inverse transform to get back the original image. Then we will compare the results to see the level of quality produced. This example is done using magnitude and phase components with a normal Q16 ImageMagic compilation.


	convert lena.png -fft -ift lena_mp_roundtrip.png

	compare -metric rmse lena.png lena_mp_roundtrip.png null:
	107.986 (0.00164776)
[IM Output] ==> [IM Output]

Thus, we see that there is about 0.16% root mean squared error, which is about typical of the process.

Now lets do the same with real and imaginary components using an hdri-enabled Q16 ImageMagick compilation.

	convert lena.png +fft +ift lena_ri_roundtrip.png

	compare -metric rmse lena.png lena_ri_roundtrip.png null:
	78.7053 (0.00120097)
[IM Output] ==> [IM Output]

In this case, there is about 0.12% root mean squared error, which is due to the higher precision that can be achieve under hdri.

Now, lets do the forward and inverse transforms as separate steps to compute the magnitude and phase and then the spectrum from the magnitude, so that one can visualize the results. First, lets get the magnitude and phase images as lena_mp_fft-0.png and lena_mp_fft-1.png.


	convert lena.png -fft lena_mp_fft.png
[IM Output] [IM Output]

We see that the magnitude image, as mentioned earlier, appears totally black. So now, lets enhance the magnitude with a log transform to produce the 'spectrum' image. We first use -contrast-stretch 0 to stretch the channels to full dynamic range. Then we apply a log transformation using the log argument to the -evaluate option to enhance the darker values in comparison to the brighter values. A log of 10,000 is used to bring out the detail.


	convert lena_mp_fft-0.png -contrast-stretch 0 -evaluate log 10000 lena_spectrum.png
[IM Output] ==> [IM Output]

Now we can see the detail in the spectrum version of the magnitude image.

Finally, we inverse transform the original magnitude and phase images to get back the original Lena image.


  convert lena_mp_fft-0.png lena_mp_fft-1.png -ift lena_mp_roundtrip.png
[IM Output] [IM Output] ==> [IM Output]

It is important to remember, however, that you can not use the spectrum image for the inverse "-ift" transform, since that will produce overly bright image.


convert lena_spectrum.png lena_mp_fft-1.png -ift lena_mp_roundtrip_fail.png
[IM Output] [IM Output] ==> [IM Output]

Basically, as you have enhanced the 'magnitude' image, you have also enhanced the resulting image in the same way, which produces the badly 'clipped' result shown above.


Properties Of The Fourier Transform

The following is a list of some of the important properties of the Fourier Transform.

  • High frequencies in the FFT (corresponding to rapidly varying intensities in the original image) lie near the outer parts of the spectrum.
  • Low frequencies in the FFT (corresponding to slowly varying intensities in the original image) lie near the center of the spectrum.
  • The zero frequency (DC) point in the FFT for an NxM original image lies at coordinates N/2,M/2.
  • The intensity value in the magnitude image at the DC point is equal the average graylevel in the original image. (This is a consequence of the scaling of the forward transform by 1/N).
  • Edges in an image give rise to transform components lying along lines perpendicular to the edges.
  • Smaller objects have more spread-out transforms; Larger objects have more compressed transform.
  • If one rotates the image, the transform rotates the same amount.
  • The transform of a uniform object lies along a line perpendicular to the dimension of the object.
  • The transform of a set of grid lines of spacing x=a,y=b in image size NxM is an array of dots: The spacing of the dots in the spectrum will be Dx=N/a and Dy=M/b.
  • The transform of a constant rectangle of dimension x=a,y=b in an image of size NxM is a sinc function: sinc(x*a/N)*sinc(y*b/M), where the sinc(x)=sin(π*x)/(π*x). Here is an example of what a sinc function looks like with a=8 and b=16 and profiles of its center row and column. The scaling factors of plus 0.21 and divide by 1.21 are because the sinc function ranges from -0.21 to 1 and thus has negative values that would otherwise be clipped in the image. Profiles of the log enhanced sinc are also displayed to show how it amplifies the smaller signals relative to the larger ones. (The 3D graphs shown below were not created with ImageMagick, but from an ImageJ plugin.) An important feature of the sinc function is that the spacing between its zeroes is a constant given by Dx=N/(a/2) and Dy=M/(b/2).


    	N=128
    	a=8
    	b=16
    	convert \( -size ${N}x1 xc: \
    		-fx "ax=$a*pi*(i-w/2)/w; ax==0?1:(sin(ax)/ax+0.21)/1.21" -scale 128x128! \) \
    		\( -size 1x${N} xc: \
    		-fx "by=$b*pi*(j-h/2)/h; by==0?1:(sin(by)/by+0.21)/1.21" -scale 128x128! \) \
    		-compose multiply -composite -contrast-stretch 0 -write sinc8x16.png \
    		-evaluate log 10 sinc8x16_log10.png

    	im_profile -s sinc8x16.png[128x1+0+64] sinc8x16h_profile.png
    	convert sinc8x16.png[1x128+64+0] -rotate 90 miff:- | \
    		im_profile - sinc8x16v_profile.png
    	im_profile -s sinc8x16_log10.png[128x1+0+64] sinc8x16h_log10_profile.png
    	convert sinc8x16_log10.png[1x128+64+0] -rotate 90 miff:- | \
    		im_profile - sinc8x16v_log10_profile.png

    [IM Output] [IM Output] [IM Output] [IM Output]
    [IM Output] [IM Output] [IM Output] [IM Output]

    The absolute value of the sinc function is what corresponds to the magnitude of the transform. Since the sinc function has positive and negative lobes, when you take the absolute value, you double the number of oscillations. Therefore, in the spectrum, the spacing of importance is between the middle of successive dark troughs (which were the locations of the zeros before taking the absolute value). This spacing then becomes Dx=N/a and Dy=M/b, due to the doubling of the oscillations. Here is the same example, but with the log of the absolute value. Profiles of the center row and column are shown as well.


    	N=128
    	a=8
    	b=16
    	convert \( -size ${N}x1 xc: \
    		-fx "ax=$a*pi*(i-w/2)/w; ax==0?1:abs(sin(ax)/ax)" -scale 128x128! \) \
    		\( -size 1x${N} xc: \
    		-fx "by=$b*pi*(j-h/2)/h; by==0?1:abs(sin(by)/by)" -scale 128x128! \) \
    		-compose multiply -composite -contrast-stretch 0 \
    		-evaluate log 100 sinc8x16abs_log100.png

    	im_profile -s sinc8x16abs_log100.png[128x1+0+64] sinc8x16absh_log100_profile.png
    	convert sinc8x16abs_log100.png[1x128+64+0] -rotate 90 miff:- | \
    		im_profile - sinc8x16absv_log100_profile.png

    [IM Output] [IM Output] [IM Output] [IM Output]

  • The transform of a constant circle of diameter d in an image of size NxN is a jinc function: jinc(r*d/N), where jinc(r)=J1(πr)/(πr) and J1(r) is the Bessel function of the first kind of order one. A jinc function would be similar to a circularly symmetric sinc function, but its side lobes are much more suppressed than in the sinc function. Also in the jinc function, the spacing between successive zeroes is not constant as it was in the sinc function. Therefore we use the spacing from the center to the first zero, which is Dr=1.22*N/d. The factor of 1.22 is identified in Theory Of Remote Image Formation and is the first zero in the Bessel function divided by pi. Here is an example of what a jinc function looks like with d=12 and also a profile of its center row. The scaling factors of plus 0.06613 and divide by 0.56613 are because the jinc function ranges from -0.06613 to 0.5 and thus has negative values that would otherwise be clipped in the image. Note that the jinc function is very difficult to compute and a series approximation to the Bessel function is used to evaluate it, which was obtained from The Handbook Of Mathematical Functions by Abramowitz and Stegun, formula 9.4.1 and 9.4.3, p369-370. We speed it up by computing it in 1D as a look up table (lut) image and then apply the lut image to a radial-gradient using the -clut option.


    	N=128
    	N2=`convert xc: -format "%[fx:sqrt(2)*$N]" info:`
    	d=12
    	rad=`convert xc: -format "%[fx:$N/2]" info:`
    	rad2=`convert xc: -format "%[fx:sqrt(2)*$rad]" info:`
    	fact=`convert xc: -format "%[fx:pi*$d/$N]" info:`
    	a0=0.5; a1=-.56249985; a2=.21093573; a3=-.03954289; a4=.00443319; a5=-.00031781; a6=.00001109
    	uu="(xx/3)"
    	xxa="($a0+$a1*pow($uu,2)+$a2*pow($uu,4)+$a3*pow($uu,6)+$a4*pow($uu,8)+$a5*pow($uu,10)+$a6*pow($uu,12))"
    	b0=.79788456; b1=.00000156; b2=.01659667; b3=.00017105; b4=-.00249511; b5=.00113653; b6=-.00020033
    	c0=-2.35619; c1=.12499612; c2=-.00005650; c3=-.00637879; c4=.00074348; c5=.00079824; c6=-.00029166
    	iuu="(3/xx)"
    	vv="($b0+$b1*$iuu+$b2*pow($iuu,2)+$b3*pow($iuu,3)+$b4*pow($iuu,4)+$b5*pow($iuu,5)+$b6*pow($iuu,6))"
    	ww="(xx+$c0+$c1*$iuu+$c2*pow($iuu,2)+$c3*pow($iuu,3)+$c4*pow($iuu,4)+$c5*pow($iuu,5)+$c6*pow($iuu,6))"
    	xxb="$vv*cos($ww)/(xx*sqrt(xx))"
    	convert -size 1x${rad2} gradient: -rotate 90 \
    		-fx "xx=$fact*i; (xx<=3)?($xxa+0.06613)/0.56613:($xxb+0.06613)/0.56613" jinc12_lut.png
    	convert \( -size ${N2}x${N2} radial-gradient: -negate -gravity center -crop ${N}x${N}+0+0 +repage \) \
    		jinc12_lut.png -clut -write jinc12.png \
    		-contrast-stretch 0 -evaluate log 10 jinc12_log10.png

    	im_profile -s jinc12.png[128x1+0+64] jinc12_profile.png
    	im_profile -s jinc12_log10.png[128x1+0+64] jinc12_log10_profile.png

    [IM Output] [IM Output] [IM Output]
    [IM Output] [IM Output] [IM Output]

    The absolute value of the jinc function is what corresponds to the magnitude of the transform. Since the jinc function has positive and negative lobes, when you take the absolute value, you double the number of oscillations. Therefore, in the spectrum, the spacing, Dr=1.22*N/d, corresponds to that from the center to the middle of the first dark trough (which used to be the location of the first zero). Here is the same example, but with the log of the absolute value. And we also graph the center row.


    	N=128
    	N2=`convert xc: -format "%[fx:sqrt(2)*$N]" info:`
    	d=12
    	rad=`convert xc: -format "%[fx:$N/2]" info:`
    	rad2=`convert xc: -format "%[fx:sqrt(2)*$rad]" info:`
    	fact=`convert xc: -format "%[fx:pi*$d/$N]" info:`
    	a0=0.5;    a1=-.56249985;    a2=.21093573; a3=-.03954289;
    	a4=.00443319;    a5=-.00031781;    a6=.00001109
    	uu="(xx/3)"
    	xxa="($a0+$a1*pow($uu,2)+$a2*pow($uu,4)+$a3*pow($uu,6)
    	xxa="$xxa+$a4*pow($uu,8)+$a5*pow($uu,10)+$a6*pow($uu,12))"
    	b0=.79788456; b1=.00000156; b2=.01659667;
    	b3=.00017105; b4=-.00249511; b5=.00113653; b6=-.00020033
    	c0=-2.35619; c1=.12499612; c2=-.00005650;
    	c3=-.00637879; c4=.00074348; c5=.00079824; c6=-.00029166
    	iuu="(3/xx)"
    	vv="($b0+$b1*$iuu+$b2*pow($iuu,2)+$b3*pow($iuu,3)"
    	vv="$vv+$b4*pow($iuu,4)+$b5*pow($iuu,5)+$b6*pow($iuu,6))"
    	ww="(xx+$c0+$c1*$iuu+$c2*pow($iuu,2)+$c3*pow($iuu,3)"
    	ww="$ww+$c4*pow($iuu,4)+$c5*pow($iuu,5)+$c6*pow($iuu,6))"
    	xxb="$vv*cos($ww)/(xx*sqrt(xx))"

    	convert -size 1x${rad2} gradient: -rotate 90 \
    		-fx "xx=$fact*i; (xx<=3)?abs($xxa):abs($xxb)" jinc12abs_lut.png

    	convert \( -size ${N2}x${N2} radial-gradient: -negate \
    		 -gravity center -crop ${N}x${N}+0+0 +repage \) \
    		jinc12abs_lut.png -clut \
    		-contrast-stretch 0 -evaluate log 100 \

    	im_profile -s jinc12abs_log100.png[128x1+0+64] jinc12abs_log100_profile.png

    [IM Output] [IM Output] [IM Output]

  • The transform of a Gaussian function of sigma=d in an image size NxN is a Gaussian function. The sigma of the Gaussian function in the spectrum will be sigma=N/(2d). See Fourier Transform Gaussian.
  • The phase looks uninteresting, but contains more information than the magnitude with regard to reconstructing the original image as something visually recognizable.
  • Convolution in the spatial domain is equivalent to multiplication in the frequency domain.
  • Other properties and characteristics are defined mathematically at either http://www.ph.tn.tudelft.nl/Courses/FIP/noframes/fip-Properti-2.html or http://en.wikipedia.org/wiki/Fourier_transform

Spectrum Of A Constant Image

Lets demonstrate some of these properties. First lets simply take a constant grayscale image and get its magnitude. The result is that magnitude image has single dot at the zero frequency or DC point in the middle of the image at coordinates (N/2,M/2) whose value is just the average grayscale value of the input image. Since the image is pure white, the magnitude at the DC point will be white and so does not require log scaling to make that visible. Therefore the magnitude and the spectrum are equivalent in this case.


	convert -size 128x128 xc:white \
		-write white.png -fft -delete 1 white_magnitude.png

	convert white_magnitude.png -format "%[fx:s.p{64,64}]" info:
	1
[IM Output] ==> [IM Output]

If we do the same on any other value of gray, then the value at the center of the magnitude will be less, in this case .5 or gray(50%), and we must apply the log to the magnitude to make the spectrum so that the center dot is visible. In this case, of course the -contrast-stretch would have sufficed by itself.


	convert -size 128x128 xc:"gray(50%)" \
		-write gray.png -fft -delete 1 -write gray_magnitude.png \
		-contrast-stretch 0 -evaluate log 100 gray_spectrum.png

	convert gray_magnitude.png -format "%[fx:s.p{64,64}]" info:
	0.500008
[IM Output] ==> [IM Output]

Now let's take a constant color image and get its magnitude.

	convert -size 128x128 xc:gold constant.png
	convert constant.png -fft +delete constant_magnitude.png
[IM Output] ==> [IM Output]

Note that the magnitude image in this case is really pure black, except for a single colored pixel in the very center of the image at the pixel location width/2, height/2. This pixel is the zero frequency or DC ('Direct Current') value of the image, and is the one pixel that does not represent a sine wave. In other words it is just the FFT constant component!

To see this single pixel more clearly lets also magnify that area of the image...

	convert constant_magnitude.png -gravity center -extent 5x5 \
	-scale 2000% constant_dc_zoom.gif
[IM Output]

Note that the color of the DC point is the same as the original image.

Actually, it is a good idea to remember that what you are seeing is three values. That is the FFT image generated is actually three separate Fast Fourier transforms, one for each of the three red, green and blue image channels. The FFT itself has no real knowledge about colors, only the channel values or 'gray-levels'.

Effects of the DC Color

In a more typical non-constant image, the DC value is the average color of the image. The color you should generally get if you had completely blurred, averaged, or resized the image down to a single pixel or color.

For example lets extract the DC pixel from the FFT of the "Lena" image.

	convert lena.png -fft +delete lena_magnitude.png
	convert lena_magnitude.png -gravity center -extent 1x1 \
		-scale 60x60   lena_dc_zoom.gif
[IM Output] ==> [IM Output] ==> [IM Output]

As you can see the average color for the image is a sort of 'dark pink' color.

Another way of thinking about this special pixel is that it represents the center 'bias' level for all the sine waves.

For example lets replace that 'dark pink' DC pixel with some other color such as the more orange color 'tomato'...

	convert -size 60x60 xc:tomato tomato_swatch.gif

	convert lena.png -fft \
		\( -clone 0  -fill tomato -draw "point 128,128" -alpha off \) \
		-delete 0 +swap -ift lena_dc_replace.png
[IM Output] ==> [IM Output]

What is really happening is that by changing the DC value in the FFT magnitude, you are changing the whole image in that same way. This is how changing the average color of the image gets replicated from the 'frequency domain' back into the 'spatial domain'.

This is not a recomended method of color tinting an image as there are other more direct means. But it is an effective approach.

Spectrum Of A Sine Wave Image

Next, lets take a look at the spectrum from a single sine wave image with 4 cycles. We see that it has 3 dots. The center dot is at zero x and y frequencies, i.e. the DC point, and in the original magnitude has a value equal to the average over the whole input image channel. The other two dots are at the positive and negative frequencies of the sine wave. As the sine wave has n=4 cycles along the x direction only, the position of the two sides dots will be 4 pixels to the left and right of the center dot.


	convert -size 128x129 gradient: -chop 0x1 -rotate 90 -evaluate sine 4 sine4.png
	convert sine4.png -fft +delete \
		-contrast-stretch 0 -evaluate log 100  sine4_spectrum.png
[IM Output] ==> [IM Output]

If we repeat this with a sine wave with 16 cycles, then again we see that it has 3 dots, but the dots are further apart, since the waves are closer together. In this case the side dots are spaced 16 pixels to the left and right sides of the center dot.

	convert -size 128x129 gradient: -chop 0x1 -rotate 90 -evaluate sine 16 sine16.png
	convert sine16.png -fft +delete \
		-contrast-stretch 0 -evaluate log 100 sine16_spectrum.png
[IM Output] ==> [IM Output]

Spectrum Of A Rectangle Pattern Image

Next, lets look at the spectrum of white rectangle of width 8 and height 16 inside a black background.


	convert -size 8x16 xc:white -gravity center -background black -extent 128x128 \
		-write rect8x16.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 rect8x16_spectrum.png
[IM Output] ==> [IM Output]

Notice that this looks like the image that we directly obtained from the absolute value of the sinc function earlier. If we graph the center row and column, we get


	im_profile -s rectangle_spectrum.png[128x1+0+64] rectangle_spec_row_profile.png

	convert rect8x16_spectrum.png[1x128+64+0] -rotate 90 miff:- |\
		im_profile -s - rect8x16_spec_col_profile.png
[IM Output] ==> [IM Output]

This clearly demonstrates that the transform of the rectangular shape is indeed a sinc function and that the narrower dimension of the object in the image produces a transform with features that are more spread out and wider. According to the properties listed above, the spacing in each dimension between the troughs is determined by N/a and N/b. Thus, when the width and height of the rectangle are a=8 and b=16, then the spacings should be 128/8=16 horizontally and 128/16=8 vertically. This is indeed what one measures for the spacing between the dark troughs in this image.

Now, lets rotate the rectangle by 45 degrees. We find that the spectrum is also rotated in the same direction by 45 degrees.


	convert rect8x16.png -rotate 45 -gravity center -crop 128x128+0+0 +repage \
		-write rect8x16_rot45.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 rect8x16_rot45_spectrum.png
[IM Output] ==> [IM Output]

Spectrum Of A Flat Circular Pattern Image

Next, lets look at the spectrum from an image with a white, flat circular pattern, in one case with diameters of 12 (radius 6) and in another case with diameter of 24 (radius 12).


	convert -size 128x128 xc:black -fill white  \
		-draw "circle 64,64 64,70" -alpha off -write circle6.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 circle6_spectrum.png

	convert -size 128x128 xc:black -fill white  \
		-draw "circle 64,64 64,76" -alpha off -write circle12.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 circle12_spectrum.png
[IM Output] ==> [IM Output]
[IM Output] ==> [IM Output]

Note that the first image is very close to what we generated for the jinc example further above. It is however a little broken up. This artifacting occurs due to the small size of the circle. Since it is represented digitally, its perimeter is not perfectly circular. The transform of the larger circle is better as its perimeter is a closer approximation of a true circle. We therefore conclude that indeed the transform of the flat circular shape is a jinc function and that the image containing the smaller diameter circle produces transform features that are more spread out and wider. According to the properties listed above, the distance from the center to the middle of the first dark ring in the spectrum will be 1.22*N/d. When the diameter of the circle is d=12, we get a distance of 1.22*128/12=13. Likewise when the diameter of the circle is d=24, we get a distance of 1.22*128/24=6.5. These are the values that one measures in those images.

Spectrum Of A Gaussian Pattern Image

Next, lets look at the spectrum from two images, each with a white Gaussian circular pattern having sigmas of 8 and 16, respectively


	convert -size 128x128 xc:black -fill white \
		-draw "point 64,64" -gaussian-blur 0x8 -contrast-stretch 0 \
		-alpha off -write gaussian8.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 gaussian8_spectrum.png

	im_profile -s gaussian8.png[128x1+0+64] gaussian8_profile.png
	im_profile -s gaussian8_spectrum.png[128x1+0+64] gaussian8_spectrum_profile.png
[IM Output] ==> [IM Output]
[IM Output] ==> [IM Output]


	convert -size 128x128 xc:black -fill white \
		-draw "point 64,64" -gaussian-blur 0x16 -contrast-stretch 0 \
		-alpha off -write gaussian16.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100 gaussian16_spectrum.png

	im_profile -s gaussian16.png[128x1+0+64] gaussian16_profile.png
	im_profile -s gaussian16_spectrum.png[128x1+0+64] gaussian16_spectrum_profile.png
[IM Output] ==> [IM Output]
[IM Output] ==> [IM Output]

This shows that the transform of the Gaussian circular shape is another Gaussian and that the larger the sigma in the original image, the smaller the sigma will be in the spectrum. From the properties stated above, we know that the sigma in the spectrum will be just N/(2*sigma), where sigma is from the original image. So for an image of size N and sigma=8, the sigma in the spectrum will be 128/16=8. Similarly if the image's sigma is 16, then the sigma in the spectrum will be 128/32=4.

Spectrum Of A Grid Pattern Image

Next, lets transform an image containing just a set of grid lines spaced 16x8 pixels apart. The resulting spectrum is just an array of dots where the grid lines that are more closely spaced produce dots further apart and vice versa. According to the properties above, since the grid lines are spaced 16x8 pixels apart, then the dots should be spaced N/a=128/16=8 and M/b=128/8=16, which is just what is measured in this image.


	convert -size 16x8 xc:white -fill black \
		-draw "line 0,0 15,0" -draw "line 0,0 0,7" \
		-alpha off -write mpr:tile +delete \
		-size 128x128 tile:mpr:tile \
		-write grid16x8.png -fft -delete 1 \
		-contrast-stretch 0 -evaluate log 100000 grid16x8_spectrum.png
[IM Output] ==> [IM Output]

Image Reconstructed From Magnitude Or Phase Only

Both the magnitude and the phase are important in the Fourier Transform. However, is one more important than the other? First let's look at the statistics of the two components.


	convert lena.png -fft -format "channel=%s; min=%[min]; max=%[max]" info:
	channel=0; min=0; max=46319.2
	channel=1; min=0.01993; max=65535

As expected, we see that both components are always non-negative. The magnitude (first channel) is by definition non-negative. The phase (second channel) has been scaled intentionally from a range between -pi and pi to full dynamic range between 0 and quantumrange, which is 65535 for Q16. Thus both components look equally important.

To get further insight, lets try reconstructing an image from either just its magnitude component or just its phase component.


	convert lena.png -fft lena_mp_fft.png

	convert lena_mp_fft-0.png \( -size 256x256 xc:gray \) -ift lena_mag_ift.png

	convert \( -size 256x256 xc:gray \) lena_mp_fft-1.png -ift lena_phase_ift.png
[IM Output] ==> [IM Output] [IM Output]
[IM Output] [IM Output]

What we find is that the reconstruction from the phase contains the edge features in the original image, whereas the magnitude image contains most of the coloring from the original image. You can recognize the girl in the phase reconstructed image, but you cannot see anything resembling her in the magnitude reconstructed image.

Image Reconstructed From Real Or Imaginary Only

Finally, lets see about the relative importance of the real and imaginary components. Again we use hdri-enabled Q16 ImageMagick compilation as both the real and imaginary components contain positive and negative values. First lets look at the statistics of the two components.


	convert lena.png +fft -format "channel=%s; min=%[min]; max=%[max]; mean=%[mean]" info:
	channel=0; min=-2521.81; max=46319.2; mean=0.63663
	channel=1; min=-2770.91; max=2770.91; mean=0.000439742

As we expected, both channels contain both positive and negative values. But The real component has a relatively small negative minimum and a relatively large positive maximum. On the other hand, the imaginary component has both a relatively small negative minimum and a relatively small positive maximum. Both are about equal in absolue value and its mean is about zero. This suggests that the imaginary component is perhaps less important than the real component.

So, lets try reconstructing an image from either just its real component or just its imaginary component.


	convert lena.png +fft +adjoin lena_ri_fft.tif

	convert lena_ri_fft-0.tif \( -size 256x256 xc:black \) +ift lena_real_ift.png

	convert \( -size 256x256 xc:white \) lena_ri_fft-1.tif +ift lena_imag_ift.png
[IM Output] ==> [IM Output] [IM Output]
[IM Output] [IM Output]

Note that the real and imaginary results of the +fft are saved in TIFF format, since that supports 32-bit values. However, most browsers (Safari being the apparent exception) will not display them. So they have been converted to PNG format for display. Consequency, those images cannot be used for further processing as PNG does not support 32-bits per channel. The proper TIFF files are needed.

So it would appear that in this case, neither does a good job. Since both components have relatively similar strengths for min and max, they both are important. But as the imaginary component has a much smaller max value, its reconstruction is poorer. For example, the ratio of max values for imaginary vs real is about (2770.91/46319.2)=0.6 or 60%.

However, might it be possible under the right circumstances that only the real component might be sufficient. The answer is yes. In particular when using and image that is mostly black with just a little white in it. This is the case of the blurring filters as exampled by the simple white rectangle or white circle shown earlier. So lets repeat this for one of these cases, say the circle of diameter 12.


	convert circle6.png +fft -format "channel=%s; min=%[min]; max=%[max]; mean=%[mean]" info:
	channel=0; min=-499.375; max=505.504; mean=0.000602056
	channel=1; min=-0.271139; max=0.271139; mean=-9.94399e-07

	convert circle6.png +fft +adjoin circle6_ri_fft.tif

	convert circle6_ri_fft-0.tif \( -size 128x128 xc:black \) +ift circle6_real_ift.png
	compare -metric rmse circle6.png circle6_real_ift.png null:
	63.2857 (0.000965678)

	convert \( -size 128x128 xc:white \) circle6_ri_fft-1.tif +ift circle6_imag_ift.png
[IM Output] ==> [IM Output] [IM Output]
[IM Output] [IM Output]

Here the ratio of max values for imaginary vs real is about (0.271139/505.504)=0.0005 or about 0.05%. So in the case of the circle, the real component alone virtually reproduces the original. This will be important later as it shows that for such simple filter images, in practice, the imaginary component (or phase component) of the filter can often be ignored.

Practical Applications

OK, now that we have covered the basics, what are the practical applications of using the Fourier Transform?

Some of the things that can be done include: 1) increasing or decreasing the contrast of an image, 2) blurring, 3) sharpening, 4) edge detection and 5) noise removal.

Changing The Contrast Of An Image - Coefficient Rooting

One can adjust the contrast in an image by performing the forward Fourier transform, raising the magnitude image to a power and then using that with the phase in the inverse Fourier transform. To increase, the contrast, one uses an exponent slightly less than one and to decrease the contrast, one uses an exponent slightly greater than one. So lets first increase the contrast on the Lena image using an exponent of 0.9 and then decrease the contrast using an exponent of 1.1.


	convert lena.png -fft \
		\( -clone 0 -evaluate pow 0.9 \) -delete 0 \
		+swap -ift lena_plus_contrast.png

	convert lena.png -fft \
		\( -clone 0 -evaluate pow 1.1 \) -delete 0 \
		+swap -ift lena_minus_contrast.png
[IM Output] ==> [IM Output]
[IM Output] ==> [IM Output]

Blurring An Image - Low Pass Filtering

One of the most important properties of Fourier Transforms is that convolution in the spatial domain is equivalent to simple multiplication in the frequency domain. In the spatial domain, one uses small, square-sized, simple convolution filters (kernels) to blur an image with the -convolve option. This is called a low pass filter. The simplest filter is just a an equally-weighted, square array. That is all the values are ones, which are normalized by dividing by their sum before applying the convolution. This is equivalent to a local or neighborhood average. Another low pass filter is the Gaussian-weighted, circularly shaped filter provided by either -gaussian-blur or -blur.

In the frequency domain, one type of low pass blurring filter is just a constant intensity white circle surrounded by black. This filter corresponds to the magntitude (or real) component and there is no (or a zero) phase (or imaginary) component as we discussed above. This filter would be similar to a circularly shaped averaging convolution filter in the spatial domain. However, since convolution in the spatial domain is equivalent to multiplication in the frequency domain, all we need do is perform a forward Fourier transform of the image, then multiply the filter with the magnitude image and finally perform the inverse Fourier transform of the product. We note that a small sized convolution filter will correspond to a large circle in the frequency domain. Multiplication is carried out via -composite with a -compose multiply setting.

So let's try doing this with two sizes of circular filters, one of diameter 48 (radius 24) and the other of diameter 32 (radius 16). Note that we display the spectrum and masked spectrum, but we actually use the masked magnitude to create the blurred result.


	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "circle 128,128 152,128" -alpha off -write circle24.png \
		-clone 0 -compose multiply -composite \) \
		\( +clone -contrast-stretch 0 -evaluate log 10000 -write lena_circle24_spec.png \) \
		-delete 0,3 +swap -ift lena_circle24_blur.png

	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "circle 128,128 144,128" -alpha off -write circle16.png \
		-clone 0 -compose multiply -composite \) \
		\( +clone -contrast-stretch 0 -evaluate log 10000 -write lena_circle16_spec.png \) \
		-delete 0,3 +swap -ift lena_circle16_blur.png
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]

A bash script, fftfilter, is available to make this easier. The simplified equivalent without all the extra processing to the above is given by:


	convert size 256x256 xc:black -fill white -draw "circle 128,128 152,128" \
		-alpha off circle24.png
	fftfilter lena.png circle24.png	lena_circle24_blur.png

	convert -size 256x256 xc:black -fill white -draw "circle 128,128 144,128" \
		-alpha off circle16.png \
	fftfilter lena.png circle16.png	lena_circle16_blur.png
[IM Output] [IM Output] ==> [IM Output]
[IM Output] [IM Output] ==> [IM Output]

So we see that the image that used the smaller diameter filter produced more blurring. We also note the 'ringing' or 'ripple' effect near edges in the resulting images. This occurs because the Fourier Transform of a circle, as we saw earlier, is a jinc function, which has decreasing oscillations as it progresses outward from the center. Here however, the jinc function and the oscillations are in the spatial domain rather than in the frequency domain, as we had demonstrated earlier above.

So what can we do about this? The simplest thing is to taper the edges of the circles using various windowing functions. Alternately, one can use a filter such as a Gaussian shape that is already by definition tapered. So lets do the latter and use two Gaussian, circularly symmetric filters with sigma of 24 and 16, respectively. Here again we display the spectrum and masked spectrum, but we actually use the masked magnitude to create the blurred result.


	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x24 -contrast-stretch 0 -write gaussian24.png \
		-clone 0 -compose multiply -composite \) \
		\( +clone -contrast-stretch 0 -evaluate log 10000 -write lena_gaussian24_spec.png \) \
		-delete 0,3 +swap -ift lena_gaussian24_blur.png

	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x16 -contrast-stretch 0 -write gaussian16.png \
		-clone 0 -compose multiply -composite \) \
		\( +clone -contrast-stretch 0 -evaluate log 10000 -write lena_gaussian16_spec.png \) \
		-delete 0,3 +swap -ift lena_gaussian16_blur.png
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]

Using the bash script, fftfilter, the simplified equivalent without all the extra processing to the above is given by:


	convert -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x24 -contrast-stretch 0 gaussian24.png
	fftfilter lena.png gaussian24.png lena_gaussian24_blur.png

	convert -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x16 -contrast-stretch 0 gaussian16.png
	fftfilter lena.png gaussian16.png lena_gaussian16_blur.png
[IM Output] [IM Output] ==> [IM Output]
[IM Output] [IM Output] ==> [IM Output]

These results with the Gaussian filter are of course much better.

The bad thing about filtering in the frequency domain is that to produce a small amount of (blurring) filtering, you need a large filter, which may take longer to create. The good thing about filtering in the frequency domain is that to produce a large amount of (blurring) filtering, you only need a small filter. Therefore, the delay you pay for doing the forward and inverse Fourier transforms, can often be made up by the shorter time it takes to create and apply the filter. However, when the filter gets very small, in this case a circle, it may degrade into some other shape not intended, due to pixelization from having a digital image. However, antialiasing the boundary of the filter shape should help.

Detecting Edges In An Image - High Pass Filtering

In the spatial domain, high pass filters that extract edges from an image are often implemented as convolutions with positive and negative weights such that they sum to zero. Things are much simpler in the frequency domain. Here a high pass filter is just the negated version of the low pass filter. That is where the low pass filter is bright, the high pass filter is dark and vice versa. So in ImageMagick, all we need do is apply the -negate option to the low pass filter image. So lets apply high pass filters to the Lena image that correspond to the constant intensity and gaussian roll-off circularly symmetric filters of diameter=24 and sigma=24, respectively. Here again we display the spectrum and masked spectrum, but we actually use the masked magnitude to create the edge result.


	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "circle 128,128 152,128" -negate -alpha off -write circle24n.png \
		-clone 0 -compose multiply -composite \) \
		\( -clone 0 -contrast-stretch 0 -evaluate log 100000 circle24n.png \
		-compose multiply -composite -write lena_circle24n_spec.png \) \
		-delete 0,3 +swap -ift -normalize lena_circle24n_edge.png

	convert lena.png -fft \
		\( -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x24 -contrast-stretch 0 -negate -write gaussian24n.png \
		-clone 0 -compose multiply -composite \) \
		\( -clone 0 -contrast-stretch 0 -evaluate log 100000 gaussian24n.png \
		-compose multiply -composite -write lena_gaussian24n_spec.png \) \
		-delete 0,3 +swap -ift -normalize lena_gaussian24n_edge.png
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]
[IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output] ==> [IM Output]

Using the bash script, fftfilter, the simplified equivalent without all the extra processing to the above is given by:


	convert -size 256x256 xc:black -fill white -draw "circle 128,128 152,128" \
		-negate -alpha off -write circle24n.png
	fftfilter lena.png circle24n.png lena_circle24n_edge.png

	convert -size 256x256 xc:black -fill white -draw "point 128,128" \
		-alpha off -blur 0x24 -contrast-stretch 0 -negate gaussian24n.png
	fftfilter lena.png gaussian24n.png lena_gaussian24n_edge.png
[IM Output] [IM Output] ==> [IM Output]
[IM Output] [IM Output] ==> [IM Output]

Carefully examining these two results, we see that the simple circle is not quite as good as the gaussian, as it has 'ringing' artifacts and is not quite as sharp.

Sharpening An Image - High Boost Filtering

The simplest way to sharpen an image is to high pass filter it (without the normalization stretch) and then blend it with the original image. The high pass filtering, in this case, is done in the frequency domain and the result transformed back to the spatial domain where it is blended with the original image.


	convert lena.png -fft \
		\( -clone 0 \( -size 256x256 xc:black -fill white \
		-draw "point 128,128" -blur 0x24 -contrast-stretch 0 -negate \) \
		-alpha off -compose multiply -composite \) \
		-delete 0 +swap -ift \
		lena.png -compose blend -set "option:compose:args" 100x100 -composite \
[IM Output] ==> [IM Output]

Noise Removal - Notch Filtering

Many noisy images contain some kind of patterned noise. This kind of noise is easy to remove in the frequency domain as the patterns show up as either a pattern of a few dots or lines. Recall a simple sine wave is a repeated pattern and shows up as only 3 dots in the spectrum.

In order to remove this noise, one simply, but unfortunately, has to manually mask (or notch) out the dots or lines in the magnitude image. We do this by transforming to the frequency domain, create a grayscale version of the spectrum, mask the dots or lines, threshold it, multiply the binary mask image with the magnitude image and then transform back to the spatial domain.

Lets try this on the clown image, which contains a diagonally striped dither-like pattern. First we transform the clown image to create its magnitude and phase images.


	convert clown.jpg -fft clown_fft.png
[IM Output] ==> [IM Output] [IM Output]

Next, we create the spectrum image from the magnitude, but we add an extra step to push any image values at graylevel zero to graylevel 1, so that we can preserve graylevel zero for the masked areas.


	convert clown_fft-0.png -contrast-stretch 0 -evaluate log 100000 \
		-fill "gray(1)" -opaque "gray(0)" clown_spectrum.png
[IM Output]

A bash script, spectrum, is also available to make this easier. One can use either the magnitude image for input or just provide the original image and it will convert that to the magnitude before generating the spectrum. In fact, the script does an adequate job of estimating the log scaling constant, so in fact, you may leave off the -s argument. Thus, the equivalent to the above is either of the following:


	spectrum -s 100000 clown_fft-0.png clown_spectrum.png

	or

	spectrum -m -s 100000 clown.jpg clown_spectrum.png

We see that the spectrum contains four bright star-like dots, one in each quadrant. We ignore the bright dot and lines in the middle as they represent the DC or zero frequency components in the image, i.e. the constant intensity regions. So now we need to mask out those star-like dots. We could display this image in ImageMagick and use the display functions to measure the locations and sizes of the star-like dots; then use -draw to cover them with black circles or rectangles. But it is easier to use some other tool such as GIMP or Photoshop to do this interactively and then threshold the result to a binary image using ImageMagick. The results are shown below.

	convert clown_spectrum_mask.png -threshold 0 clown_mask.png
[IM Output] ==> [IM Output]

You can even draw in color and then extract the mask as follows:


	convert clown_spectrum_edited.png -fill white +opaque red \
		-fill black -opaque red clown_mask2.png
[IM Output] ==> [IM Output]

Now we simply multiply the mask with the magnitude and use the result with the phase image to transform back to the spatial domain. We display the original image next to it for comparison. Here again we display the spectrum, but we actually mask the magnitude to create the filtered result.


	convert \( clown_mask.png clown_fft-0.png -compose multiply -composite \) \
		clown_fft-1.png -ift clown_filtered.png
[IM Output] ==> [IM Output] ==> [IM Output] vs [IM Output]

We note, however, that there is some 'ringing' artifacts remaining in the result. This can be removed by tapering the sharp white-to-black transitions in the mask. One can use a Gaussian shaped taper as we did before or even simply a linear taper of 5 pixels. Note that -blur radiusx65000 will produce such a linear taper.


	convert \( clown_mask.png -blur 5x65000 -write clown_mask_taper.png \) \
		clown_fft-0.png -compose multiply -composite \
		clown_fft-1.png -ift clown_filtered_taper.png
[IM Output] ==> [IM Output] ==> [IM Output] vs [IM Output]

Both examples above become simpler using the script, fftfilter (after creating the mask).


	fftfilter clown.jpg clown_mask.png clown_filtered.png

	fftfilter clown.jpg clown_mask_taper.png clown_filtered_taper.png
[IM Output] [IM Output] ==> [IM Output]
[IM Output] [IM Output] ==> [IM Output]

We can even take the difference between the original and the result to create an image that is just the noise that was removed.

	convert clown.jpg clown_filtered_taper.png -compose difference \
		-composite -normalize clown_noise.png
[IM Output]

Lets try this on an another example. This time on the twig image, which contains an irregular horizontal and vertical striped patter. First we transform the twig image to create its magnitude and phase images. Then, we create a graylevel spectrum image from the magnitude with graylevel zero preserved for the masked areas.

	convert twig.jpg -fft twig_fft.png

	spectrum -c 100000 twig_fft-0.png twig_spectrum.png
[IM Output] ==> [IM Output]

In this case, as the noise in the image is horizontally and vertically oriented, this shows up as vertical and horizontal bright areas along the center of the spectrum. So we mask those out, again manually, using GIMP or Photoshop. Then we threshold the result in ImageMagick to form a binary mask.


	convert twig_spectrum_mask.png -threshold 0 twig_mask.png
[IM Output] [IM Output]

Now we again multiply the mask with the magnitude and use the result with the phase image to transform back to the spatial domain. The result is presented next to the original image for comparison. Here again we display the spectrum, but we actually mask the magnitude to create the filtered result.


	convert \( twig_mask.png twig_fft-0.png -compose multiply -composite \) \
		twig_fft-1.png -ift twig_filtered.png
[IM Output] ==> [IM Output] ==> [IM Output] vs [IM Output]

Again just using the script (after creating the mask), fftfilter, we get:


	fftfilter twig.jpg twig_mask.png twig_filtered.png
[IM Output] [IM Output] ==> [IM Output]

Now we can take the difference between the original and the result to create an image that is just the noise that was removed


	convert twig.jpg twig_filtered.png -compose difference \
		-composite -normalize twig_noise.png
[IM Output]

Advanced Applications

Some of the other more advanced applications of using the Fourier Transform include: 1) deconvolution (deblurring) of motion blurred and defocused images and 2) normalized cross correlation to find where a small image best matches within a larger image.

However, as these applications generally require the use of the real and imaginary components of the Fourier Transform and/or very high precision, we must do the processing using Q32 or an HDRI compiled version of IM 6.5.4-7 or later until proper ImageMagick functions can be made for them. When that occurs, the HDRI restriction can be lifted. The examples below were processed using a Q16 HDRI compilation of ImageMagick.

Convolution And Deconvolution

In the spatial domain, the process of blurring or edge detection of an image is usually accomplished with convolutions. That is, the image is convolved with a small kernel or filter. For example, a 3x3 array of ones, is a small blurring (averaging) filter. In ImageMagick, this 2D array of ones is simply supplied as a 1D list of ones to the -convolve option. However, in other systems, the filter is represented as a small image, for example, of size 3x3 containing only values of 1 or white pixels for the averaging filter. However, in principal, it could be padded out with black pixels on all sides to any size desired and one would get the same result, only slower.

One of the Fourier Transform principles that was listed earlier is that in the frequency domain, the equivalent of convolution is multiplication. Therefore, blurring or edge detection in the frequency domain is simply the multiplication, pixel-by-pixel, between the Fourier Transform of the image and the Fourier Transform of the appropriate filter image.

Likewise, the process of deconvolution (or deblurring), which is hard if not impossible in the spatial domain, becomes simply a division in the frequency domain. That is, one divides the Fourier Transform of the blurred image by the Fourier Transform of the filter image that created the blurring.

So the way to convolve or deconvolve an image (digital picture) using the Fourier Transform is to create a filter in the form of a small, centered image of appropriate values and then pad it with black all around to fill it out to the same size as the picture. Then transform both this filter and the picture to the frequency domain, multiply or divide the two together pixel-by-pixel, depending upon whether one is convolving or deconvolving, respectively, and then transform back to the spatial domain.

But what do we really mean by multiplication and division in the frequency domain?

In order to understand the meaning, we recall that the Fourier Transform converts spatial intensity (graylevel) values in each image channel into complex numbers that represent the amplitudes of the exponential sinusoidal waves. We recall that these exponential sinusoidal waves are described by the following equation.

(7) [IM Output]

This has two components, the cosine, which is the real part and the sine, which is the imaginary part (because it is multiplied by i, the symbol for square root of -1). Thus we are fundamentally dealing with a complex number for both the filter (F) and the picture (P) of the form.

(8) [IM Output]

Therefore multiplication and division in the frequency domain means that for each pixel, we must multiply or divide two complex numbers. So when doing blurring in the frequency domain, we want the product of each complex filter value multiplied by the corresponding complex picture value. The product then becomes just another complex number with a real part and an imaginary part as follows. (Note that i*i=-1). See also multiplication and division of two Complex Numbers.

(9) [IM Output]

For deblurring, what we would like to do is divide each complex picture value by the corresponding complex filter value, namely, P/F. But there is actually no formal division by a complex number in real and imaginary form. However, we can multiply both the numerator and denominator by the complex conjugate of the filter, denoted as F*. A complex conjugate number is the same as the complex number, except there is a negative sign rather than a positive sign before the imaginary symbol, i. Thus the division of the complex picture by the complex filter becomes again just another complex number with a real part and an imaginary part as follows. (Note |F|2 is just a real number. It has no imaginary component).

(10) [IM Output]

One can also do complex multiplication and division using magnitude and phase components, which turns out actually to be simpler mathematics. Here, A and C are the magnitude components and B and D are the phase components.
(11) [IM Output]

Here multiplication is achieved by multiplying the two magnitude components and by adding the two phase components. See again, Complex Numbers.

(12) [IM Output]

Thus the new magnitude is just AC and the new phase is just (B+D).

For division, we can divide the two magnitude components and subtract the two phase components.
(13) [IM Output]

Thus the new magnitidue is just (C/A) and the new phase is just (D-B).

Motion Blur

Motion blur in a photograph occurs when either the object being photographed or the camera itself moves while the camera shutter is open. If this motion is linear and uniform over time, then in the spatial domain, the blurring filter may be considered simply a white straight line in a black background, since the motion is linear in one dimension and uniform. Of course the motion may be at an angle relative to horizontal and thus the line would be oriented at some angle. The length of the line corresponds directly to the amount of motion blurring.

Lets now create a 15 pixel, horizontal motion blur filter and use it to blur a picture using both multiplication approaches, first using real and imaginary components and then using magnitude and phase components. Both images will be 256x256 pixels in size, but we will display them at half size. You may not be able to see the white line in the middle of the black filter image at half size. However, you can view the full size images by clicking on the small ones.

There are two other things that must be done in practice in addition to applying the equation for complex multiplication. First, we need to "roll" the picture using the -roll option so that what is now the center of the 15 pixel long white line at coordinates (128,128) are moved to the top left at coordinates (0,0). We must do this, since that is the real origin for the Fourier Transform and the filter must be properly centered at the origin before it can be multiplied with the Fourier Transform of the image. Otherwise the opposite occurs and the resulting image will end up rolled so that its top left corner will end up at the center and vice versa. Second, we must linearly stretch the Fourier Transform of the filter or the result will be too dark. Since its maximum value is at the DC point and is equal by the mean of its spatial image, we simply need to stretch the mean value to full white. We can do this by computing the mean value and using the -level option. Alternately, we could simply use an automatic stretch such as -linear-stretch 0x1. This forces the stetch to occur on the white side from its maximum value found at the first non-empty bin (i.e. having a count of 1 or more) in the histogram to full white and leaves the black side unchanged.

To create the spatial domain motion blur filter, we simply draw a 15 pixel horizontal white line in the center of a black background using the -draw option. So if the center is 128, we draw a line from (121,128) to (135,128) so that the difference between the left and right ends is (135-121+1)=15.

Once the filter image is created in the first section below, we start the second section, which blurs the image, by first computing the mean of the filter image and save that value. Then we transform both the filter and image from the spatial domain to the frequency domain using the +fft option to create the real and imaginary components of each. Then we roll the filter so that its center is moved to the upper left corner and apply the mean to stretch both its real and imaginary components using the -level option. Once that is done, we apply equation (9) to do the complex multiply of the real and imaginary components from both the filter and image. This is accomplished with a sequence of -compose and -composite options. Finally the real and imaginary component products are returned to the spatial domain using the +ift option.

In the third section, we do the same blurrinig, but use the -fft option to create the magnitude and phase components of each. We do the same roll and stretch to the magnitude and phase of the filter and use a different set of -compose and -composite options to do the complex multiplication according to equation (12). Then we use the -ift option to return the magnitude and phase products back to the spatial domain.


	convert -size 256x256 xc:black -fill white \
		-draw "line 121,128 135,128" -alpha off motion15.png

	mean=`convert motion15.png -format "%[mean]" info:`
	convert \( motion15.png -roll -128-128 +fft -level 0x$mean \) \
		\( cameraman.png +fft \) \
		\( -clone 0 -clone 2 -compose multiply -composite \) \
		\( -clone 1 -clone 3 -compose multiply -composite \) \
		\( -clone 4 -clone 5 +swap -alpha off -compose minus -composite \) \
		\( -clone 1 -clone 2 -compose multiply -composite \) \
		\( -clone 0 -clone 3 -compose multiply -composite \) \
		\( -clone 7 -clone 8 -compose plus -composite \) \
		-delete 0,1,2,3,4,5,7,8 +ift cameraman_ri_motion15.png

	mean=`convert motion15.png -format "%[mean]" info:`
	convert \( motion15.png -roll -128-128 -fft -level 0x$mean \) \
		\( cameraman.png -fft \) \
		\( -clone 0 -clone 2 -compose multiply -composite \) \
		\( -clone 1 -clone 3 -compose add -background gray50 -flatten \) \
		-delete 0-3 -ift  cameraman_mp_motion15.png
[IM Output] [IM Output] ==> [IM Output]

[IM Output] [IM Output] ==> [IM Output]

As there is a lot to remember to do here and it involves a formidable amount of -compose and -composite options, a bash script, fftconvol, is available to do all this work. The script works as follows to achieve the same thing as what is presented in the second section above using real and imaginary fft components.


	fftconvol cameraman.png motion15.png cameraman_ri_motion15.png

This script produces the same results as depicted above.

You will need to click on the filter image to enlarge it so that you can see the white line. Then if you enlarge the original image and the motion blurred image and compare them you will notice several things indicative of motion blur. First, the blurring is only horizontally. You can see this, for example, by examining the bright spot on the top of the far, tall, narrow bright building. You will see in the motion blurred image that it is only blurred horizontally and has a nice uniform brightness to it. There is also a bright spot about 3/4 of the way down the dark part of the front two legs of the tripod. They also get blurred only horizontally. The final interesting thing to notice is that the bottom of the two front tripod legs get doubled by the large amount of motion blur.

Now lets use the same blurring filter image to deblur this picture using the division equations (10) and (13) above using, respectively, the real and imaginary division and the magnitude and phase division approaches. These are shown in the second and third sections after re-creating the same filter image in the first section.


	convert -size 256x256 xc:black -fill white \
			-draw "line 121,128 135,128" -alpha off motion15.png

	mean=`convert motion15.png -format "%[mean]" info:`
	convert \( motion15.png -roll -128-128 +fft -level 0x$mean \) \
		\( cameraman_ri_motion15.png +fft \) \
		\( -clone 0 -clone 0 -compose multiply -composite \) \
		\( -clone 1 -clone 1 -compose multiply -composite \) \
		\( -clone 4 -clone 5 -compose plus -composite \) \
		\( -clone 0 -clone 2 -compose multiply -composite \) \
		\( -clone 1 -clone 3 -compose multiply -composite \) \
		\( -clone 7 -clone 8 -compose plus -composite \) \
		\( -clone 6 -clone 9 -compose divide -composite \) \
		\( -clone 0 -clone 3 -compose multiply -composite \) \
		\( -clone 1 -clone 2 -compose multiply -composite \) \
		\( -clone 11 -clone 12 +swap -alpha off -compose minus -composite \) \
		\( -clone 6 -clone 13 -compose divide -composite \) \
		-delete 0-9,11,12,13 +ift cameraman_ri_motion15_deblur_0.png

	compare -metric rmse cameraman.png cameraman_ri_motion15_deblur_0.png null:
	188.397 (0.00287476)

	mean=`convert motion15.png -format "%[mean]" info:`
	convert \( motion15.png -roll -128-128 -fft -level 0x$mean \) \
		\( cameraman_mp_motion15.png -fft \) \
		\( -clone 0 -clone 2 -compose divide -composite \) \
		\( -clone 1 -clone 3 -compose subtract -background gray50 -flatten \) \
		-delete 0-3 -ift cameraman_mp_motion15_deblur_0.png

	compare -metric rmse cameraman.png cameraman_mp_motion15_deblur_0.png null:
	188.421 (0.00287511)
[IM Output] [IM Output] ==> [IM Output]

[IM Output] [IM Output] ==> [IM Output]

Again, as there is a lot to remember to do here and it involves an even more formidable amount of -compose and -composite options, a bash script, fftdeconvol, is available to do all this work. The script works as follows to achieve the same thing as what is presented in the second section above using real and imaginary fft components.


	fftdeconvol cameraman_ri_motion15.png motion15.png cameraman_ri_motion15_deblur_0.png

This script produces the same results as depicted above.

Now a comparison of the results with the original image shows a very small rmse value. Consequently, you might say, this is too good to be true. And you are right. In the real world, photographic pictures are not so conducive.

In particular, noise is introduced into the pictures when it is recorded to whatever is the relevant media. In film-based photography, the silver grains contribute to film grain noise. In digital photography, the sensors that define the pixel array have electronic noise. For more details on either, see Image Noise. Also see Additive White Noise. The important factor is that the noise is introduced after the blurring.

Therefore, to make a more realistic simulation of a blurred image, we need to add noise to our motion blurred image from above. This is accomplished by creating a random grayscale noise pattern and adding it to the image. Here we create a noise image that has full dynamic range and subtract mid-gray from it and then add a factor of 0.01 times the noise image to the blurred image. In doing so we have subtracted mid-gray first so as to have both positive and negative noise changes in the image. As you can see the amount of noise is so small that you cannot detect it with the naked eye.


	convert -size 256x256 xc:gray +noise random \
		-channel green -separate noise_gray.png

	convert cameraman_ri_motion15.png noise_gray.png +swap \
		-compose mathematics -set option:compose:args "0,1,0.01,-0.005" \
		-composite cameraman_motion15_noise.png

	compare -metric rmse cameraman_motion15.png cameraman_motion15_noise.png null:
	190.033 (0.00289972)

[IM Output] [IM Output] ==> [IM Output]

So now what do we get when we try to deblur this image? So that we do not repeat a large amount of duplication and to make life easier, we simply use the fftdeconvol script.


	fftdeconvol cameraman_motion15_noise.png motion15.png cameraman_motion15_noise_deblur_0.png
[IM Output] [IM Output] ==> [IM Output]

As you can see it has been deblurred, but at the cost of much more noise than we originally introduced into the blurred image. Why is this? The noise amplification occurs from the divide we do when the denominator is very small and approaches zero. This tends to amplify the noise in the image.

So what can we do about it, if anything? The answer is we can do something very simple. Just add a small number to the denominator in our complex division equation. So when the denominator gets very small, the constant will be enough to keep from dividing by something too close to zero. But when the denominator is not small, the small constant will not contribute significantly.

(14) [IM Output]

There is in fact some basis for doing this and some real meaning to the small number used in the denominator. This idea was first proposed by Norbert Wiener and the resulting deblurring approach has been named the Wiener Filter after him. The approach produces a minimum mean squared error optimal filter and the small number is determined from the noise to signal power spectrum density ratio. This is just a fancy way of expressing the ratio of the noise variance to the signal variance and can be estimated directly from the image. The signal variance can be computed from overall image variance (squared standard deviation) statistic and a noise variance can be estimated from the variance of a subsection of the image that has little signal variation, namely a region that has a constant graylevel.

The equivalent using magnitude and phase simply becomes:

(15) [IM Output]

So let's now try this on the noisy blurred image. The image below shows where the noise variance is estimated.


	convert cameraman_motion15_noise.png -fill none -stroke red \
		-draw "rectangle 240,40 249,89" -alpha off cameraman_motion15_noise_area.png

	convert cameraman_motion15_noise.png[10x50+240+40] -format "%[standard_deviation]" info:
	379.925

	convert cameraman_motion15_noise.png -format "%[standard_deviation]" info:
	16865.8

	convert xc: -format "%[fx:(379.925/16865.8.9)^2]" info:
	0.000507437
[IM Output]

Now lets deblur the noisy blurred image using the Wiener Filter approach with n=0.0005. The image in the center is this result. For comparison and to see how sensitive is the value used for n, the image to its left is the result using n=0.005 and the image to its right is the result using n=0.00005, thus using a factor of 10 larger and smaller than the center image.


	fftdeconvol -n 0.00005 cameraman_motion15_noise.png motion15.png \
[IM Output] [IM Output] ==> [IM Output] [IM Output] [IM Output]

Upon examination of the full size images, we see that the image on the left is still somewhat blurred and has some 'ghosting' artifacts, but has little amplified noise. Whereas, the image on the right is deblurred well, but has noise amplification. The center image with our measure value of n=0.0005 seems to be a reasonable compromise between residual blurring and noise amplification.

Defocus

Defocus in a picture occurs when the lens is moved from its optimal location and causes a deviation in the plane or surface of best focus. In an ideal case, the defocus filter corresponds simply to a constant intensity (white-filled) circle, although other shapes are possible and depend upon the shape of the shutter mechanism. The amount of blurring that is introduced then depends upon the diameter of the circle. When using such a spatial filter for blurring or deblurring in the frequency domain, we again center the circle and pad it out with black to fill an image the same size as the image that we want to blur or deblur.

Lets now create a 15 pixel diameter, circular defocus filter and use it to blur the same picture. Both images will be 256x256 pixels in size, but we will again display them at half size. However, you can view the full size images by clicking on the small ones. We use the exact same blurring and deblurring techniques (and scripts) as above for the case of motion blur. The only difference is the filter image that we create and apply.

To create the spatial domain defocus filter, we simply draw a 15 pixel diameter white circle in the center of a black background using the -draw option. So if the center is 128, we draw a circle whose center is at (128,128) and having a point on its perimeter to its right at (135,128). This means that the point on the perimeter to its left will be at (121,128) so that the diameter becomes (135-121+1)=15. We use the same fftonvolve script, but use the -t defocus argument to create the defocus type blurring.


	convert -size 256x256 xc:black -fill white \
		-draw "circle 128,128 135,128" -alpha off defocus15.png

	fftconvol cameraman.png defocus15.png cameraman_defocus15.png
[IM Output] [IM Output] ==> [IM Output]

Upon examining the full size images, we see that blurring occurs uniformly in all directions. Now let's deblur this image using the fftdeconvol script.


	convert -size 256x256 xc:black -fill white \
		-draw "circle 128,128 135,128" -alpha off defocus15.png

	fftdeconvol cameraman_defocus15.png defocus15.png cameraman_defocus15_deblur_0.png

	compare -metric rmse cameraman.png cameraman_defocus15_deblur_0.png null:
	693.721 (0.0105855)
[IM Output] [IM Output] ==> [IM Output]

And a comparison with the original image shows a small rmse value, but about 3 times larger than we got from the 15 pixel motion blur example above. We now add noise to the blurred image using the same random noise image that we created before.


	convert cameraman_defocus15.png noise_gray.png +swap \
		-compose mathematics -set option:compose:args "0,1,0.01,-0.005" \
		-composite cameraman_defocus15_noise.png

	compare -metric rmse cameraman_defocus15.png cameraman_defocus15_noise.png null:
	190.033 (0.00289972)
[IM Output] [IM Output] ==> [IM Output]

And now estimate the signal and noise variance and thus the number to add to the denominator term.


	convert cameraman_defocus15_noise.png -fill none -stroke red \
		-draw "rectangle 240,40 249,89" -alpha off cameraman_defocus15_noise_area.png

	convert cameraman_defocus15_noise.png[10x50+240+40] -format "%[standard_deviation]" info:
	351.106

	convert cameraman_defocus15_noise.png -format "%[standard_deviation]" info:
	16489.1

	convert xc: -format "%[fx:(351.106/16489.1)^2]" info:
	0.000453401
[IM Output]

Now we use the number n=0.0005 to deblur the image along with the blurring filter as we did before. The image in the center is this result. For comparison the image to its left is the result using n=0.005 and the image to its right is the result using n=0.00005, thus using a factor of 10 larger and smaller than the center image.


	convert -size 256x256 xc:black -fill white \
		-draw "circle 128,128 135,128" -alpha off defocus15.png

	fftdeconvol -n 0.0005 cameraman_defocus15_noise.png defocus15.png \
[IM Output] [IM Output] ==> [IM Output] [IM Output] [IM Output]

Upon examination of the full size images, we see that the image on the left is still somewhat blurred and has some 'ghosting' artifacts, but has little amplified noise. Whereas, the image on the right is deblurred well, but has noise amplification. The center image with our measure value of n=0.0005 seems to be a reasonable compromise between residual blurring and noise amplification.

Ideal Blurring And Deblurring

The approach above has one specific advantange and one specific disadvantage. The advantage is that is permits almost any kind of spatial filter that one can create in the form of an image. It is not limited to motion blur or defocus. For example, if the shutter on your camera is hexagonal rather than round, one can create a hexagonal shape for the filter. Or if you want to produce an edge result you can, for example, make a black circle in a white image for the filter. The disadvantage that it has when applying motion blur and defocus is that it transform the line and circle filter images from the spatial domain to the frequency domain. As we saw above, when one does this, for example, for a circle, the result in the frequency domain should be an image of the jinc function. But as we saw earlier, in practice, it ends up with a less than ideal form and is somewhat broken up. Here is the comparison again for the case of a 12 pixel diameter circle. On the left is the Fourier Transform spectrum of the circle image and on the right is the absolute value of the log of the ideal jinc function for the same diameter.

[IM Output] [IM Output]

Therefore another approach to blurring and deblurring, at least for motion blur and defocus, would be to create the ideal Fourier Transform filter directly without having to transform the equivalent spatial filter. We can do this, since, as we saw above, we know the form and equations that are needed to create the Fourier Transform filters for these two types of blurring. For motion blur, it is the 1D (possibly rotated) sinc function and for defocus, it is the jinc function. We note however, that we must calculate and use the actual sinc and jinc functions rather than just their absolute values. Consequently, both will have positive and negative values, which is why these filter images must be saved in HDRI compatible image types.

We also know from our experiments with real only reconstruction of the circle image that its imaginary component is relatively insignificant and so we do not need an imaginary component for the filter.

The downside to this approach is that there is no current ImageMagick option to create either the sinc or jinc function. Therefore they currently must be created with the generally slower -fx option, although we can speed things up for special cases where the sinc function's orientation is along the coordinate axes and also by using a 1D look up table to implement the radially symmetric jinc function.

On the upside side, these filters can be stored and reused later, if desired. But more importantly, the filtering operation is much simpler, since these filters have no imaginary component. Therefore, for blurring and deblurring, the corresponding multiplication and division math (with real and imaginary components) becomes:

(16) [IM Output]

(17) [IM Output]

(18) [IM Output]

Ideal Motion Blur

Now let's repeat the same motion blur by 15 pixels horizontally, but create the blurring filter in the form of the sinc function as an image for use directly in the frequency domain. To blur the image, we then use the modified multiplication equation (17) above between that sinc filter and the Fourier Transform of the image. We do not transform the filter image as it is already the equivalent filter for use in the frequency domain. Finally, we transform the product back to the spatial domain. Since the actual sinc filter has both positive and negative values, it cannot be displayed directly. Therefore, the absolute value of the log of the filter is also created for viewing purposes.


	length=15
	xfreq=`convert xc: -format "%[fx:$length*pi/256]" info:`
	convert -size 256x1 xc: \
		-fx "zz=$xfreq*(i-w/2); zz?sin(zz)/(zz):1" \
		-scale 256x256\!  \
		\( -clone 0 -clone 0 -compose multiply -composite \
		-evaluate pow 0.5 -contrast-stretch 0 \
		-evaluate log 100 -write sincfilter15_abs_log100.png \) \
		+delete sincfilter15.pfm

	convert \( cameraman.png +fft \) \
		\( -clone 0 sincfilter15.pfm -compose multiply -composite \) \
		\( -clone 1 sincfilter15.pfm -compose multiply -composite \) \
		-delete 0,1 +ift cameraman_idealmotion15.png
[IM Output] [IM Output] ==> [IM Output]

As before, a script version, camerablur, is available and its use to create the same motion bur as above is as follows.


	camerablur -t motion -a 15 -r 0 cameraman.png cameraman_idealmotion15.png

Note there is no filter image, since the script creates the sinc function internally. The argument -r 0 indicates that the motion blur will be horizontal. This is the default orientation, but other values may be supplied to produce motion blur at any angle.

And now we deblur this result using equation (18) for the complex divide operation. We can either use the filter that we created or create it again exactly as above. We will do the former. However, when one has some actual blurred image that was not artificially created, we would do the latter.


	noise=0
	qnoise=`convert xc: -format "%[fx:quantumrange*$noise]" info:`
	convert \( cameraman_idealmotion15.png +fft \) \
		\( sincfilter15.pfm sincfilter15.pfm -compose multiply -composite -evaluate add $qnoise \) \
		\( -clone 0 sincfilter15.pfm -compose multiply -composite \) \
		\( -clone 1 sincfilter15.pfm -compose multiply -composite \) \
		\( -clone 3 -clone 2 +swap -compose divide -composite \) \
		\( -clone 4 -clone 2 +swap -compose divide -composite \) \
		-delete 0-4 +ift cameraman_idealmotion15_deblur_0.png

	compare -metric rmse cameraman.png cameraman_idealmotion15_deblur_0.png null:
	188.748 (0.00288011)
[IM Output] [IM Output] ==> [IM Output]

Again a script, cameradeblur, is available and the equivlant to the above is:


	cameradeblur -t motion -a 15 -r 0 cameraman_idealmotion15.png cameraman_idealmotion15_deblur_0.png

We now add noise to the blurred image using the same random noise image that we generated before.


	convert cameraman_idealmotion15.png noise_gray.png +swap \
		-compose mathematics -set option:compose:args "0,1,0.01,-0.005" \
		-composite cameraman_idealmotion15_noise.png

	compare -metric rmse cameraman_idealmotion15.png cameraman_idealmotion15_noise.png null:
	190.033 (0.00289972)
[IM Output] [IM Output] ==> [IM Output]

And now get the noise and signal variances to estimate the noise parameter.


	convert cameraman_idealmotion15_noise.png -fill none -stroke red \
		-draw "rectangle 240,40 249,89" -alpha off cameraman_idealmotion15_noise_area.png

	convert cameraman_idealmotion15_noise.png[10x50+240+40] -format "%[standard_deviation]" info:
	379.22

	convert cameraman_idealmotion15_noise.png -format "%[standard_deviation]" info:
	16862

	convert xc: -format "%[fx:(379.22/16862)^2]" info:
	0.000505783
[IM Output]

So we again deblur using n=0.0005 and also n=0.005 and n=0.00005 for comparison. The sinc function filter image is not explicity supplied, but is created internally. We simply display it here for reference.


	cameradeblur -t motion -a 15 -r 0 -n 0.0005 cameraman_idealmotion15_noise.png \
[IM Output] [IM Output] ==> [IM Output] [IM Output] [IM Output]

Ideal Defocus

Now let's repeat the same defocus with a 15 pixel diameter, but create the blurring filter as the jinc function as an image in the frequency domain. To blur the image, we then use the modified multiplication equation (17) above between the jinc filter and the Fourier Transform of the image. We do not transform the filter image as it is already the equivalent filter for use in the frequency domain. Finally, we transform the product back to the spatial domain. Since the actual jinc filter has both positive and negative values, it cannot be displayed directly. Therefore, the absolute value of the log of the filter is also created for viewing purposes.


	diam=15
	diag=`convert xc: -format "%[fx:sqrt(2)*256]" info:`
	hdiag=`convert xc: -format "%[fx:sqrt(2)*128]" info:`
	rfreq=`convert xc: -format "%[fx:$diam*pi/256]" info:`
	a0=0.5; a1=-.56249985; a2=.21093573; a3=-.03954289; a4=.00443319; a5=-.00031781; a6=.00001109
	uu="(zz/3)"
	jinc1="($a0+$a1*pow($uu,2)+$a2*pow($uu,4)+$a3*pow($uu,6)+$a4*pow($uu,8)+$a5*pow($uu,10)+$a6*pow($uu,12))"
	b0=.79788456; b1=.00000156; b2=.01659667; b3=.00017105; b4=-.00249511; b5=.00113653; b6=-.00020033
	c0=-2.35619; c1=.12499612; c2=-.00005650; c3=-.00637879; c4=.00074348; c5=.00079824; c6=-.00029166
	iuu="(3/zz)"
	vv="($b0+$b1*$iuu+$b2*pow($iuu,2)+$b3*pow($iuu,3)+$b4*pow($iuu,4)+$b5*pow($iuu,5)+$b6*pow($iuu,6))"
	ww="(zz+$c0+$c1*$iuu+$c2*pow($iuu,2)+$c3*pow($iuu,3)+$c4*pow($iuu,4)+$c5*pow($iuu,5)+$c6*pow($iuu,6))"
	jinc2="$vv*cos($ww)/(zz*sqrt(zz))"
	convert -size 1x${hdiag} gradient: -rotate 90 \
		-fx "zz=hypot($rfreq*i,$rfreq*j); (zz<=3)?2*$jinc1:2*$jinc2" \
		jincfilter15_lut.pfm
	convert \( -size ${diag}x${diag} radial-gradient: -negate \
		-gravity center -crop 256x256+0+0 +repage \) \
		jincfilter15_lut.pfm -clut \
		\( -clone 0 -clone 0 -compose multiply -composite \
		-evaluate pow 0.5 -contrast-stretch 0 \
		-evaluate log 100 -write jincfilter15_abs_log100.png \) \
		+delete jincfilter15.pfm

	convert \( cameraman.png +fft \) \
		\( -clone 0 jincfilter15.pfm -compose multiply -composite \) \
		\( -clone 1 jincfilter15.pfm -compose multiply -composite \) \
		-delete 0,1 +ift cameraman_idealdefocus15.png
[IM Output] [IM Output] ==> [IM Output]

The script version of the above is just:


	camerablur -t defocus -a 15 -m fast cameraman.png cameraman_idealdefocus15.png

The -m argument allows for either a fast, but less accurate computation of the jinc or a much slower, but more accurate computation.

One point to note about the blurred result. If one looks carefully at the image, one sees some mottled darkening along the top edge and some brightening along the bottom edge. This is a result of the Fourier transform assumption that the image is periodic. In ImageMagick terms, it is the equivalent to -virtual-pixel tile. Thus the blurring along the one edge mixes those pixels with the opposite edge. The only way to avoid this is to pad the image first with mirrored pixels by an amount somewhat larger than the blur amount. So for example, let's mirror unfold this image by 22 pixels (which is larger than 15) to a size of 300x300.


	convert cameraman.png -virtual-pixel mirror \
		-set option:distort:viewport 300x300-22-22 \
		-distort SRT 0 +repage \
[IM Output]

Now lets do the same defocus blurring and crop the result back to its original size of 256x256.


	camerablur -t defocus -a 15 -m fast cameraman_mirror.png cameraman_idealdefocus15_mirror.png
	convert cameraman_idealdefocus15_mirror.png[256x256+22+22] cameraman_idealdefocus15_mirror_crop.png
[IM Output]

This results in a higher quality image without the artifacts at the top and bottom.

And now we go back and deblur the earlier result using equation (18) for the complex divide operation. We can either use the filter that we created or create it again exactly as above. We will do the former. However, when one has some actual blurred image that was not artificially created, we would do the latter.


	noise=0
	qnoise=`convert xc: -format "%[fx:quantumrange*$noise]" info:`
	convert \( cameraman_idealdefocus15.png +fft \) \
		\( jincfilter15.pfm jincfilter15.pfm -compose multiply -composite -evaluate add $qnoise \) \
		\( -clone 0 jincfilter15.pfm -compose multiply -composite \) \
		\( -clone 1 jincfilter15.pfm -compose multiply -composite \) \
		\( -clone 3 -clone 2 +swap -compose divide -composite \) \
		\( -clone 4 -clone 2 +swap -compose divide -composite \) \
		-delete 0-4 +ift cameraman_idealdefocus15_deblur_0.png

	compare -metric rmse cameraman.png cameraman_idealdefocus15_deblur_0.png null:
	970.639 (0.014811)
[IM Output] [IM Output] ==> [IM Output]

And it even reverses the artifacts that were introduced along the top and bottom edges from the Fourier transform assumption of image periodicity.

The script version of the above is just:


	cameradeblur -t defocus -a 15 -m fast cameraman_idealdefocus15.png \

We now add noise to the blurred image using the same random noise image that we generated before.


	convert cameraman_idealdefocus15.png noise_gray.png +swap \
		-compose mathematics -set option:compose:args "0,1,0.01,-0.005" \
		-composite cameraman_idealdefocus15_noise.png

	compare -metric rmse cameraman_idealdefocus15.png cameraman_idealdefocus15_noise.png null:
	190.033 (0.00289972)
[IM Output] [IM Output] ==> [IM Output]

And now we get the noise and signal variances to estimate the noise parameter.


	convert cameraman_idealdefocus15_noise.png -fill none -stroke red \
		-draw "rectangle 240,40 249,89" -alpha off cameraman_idealmotion15_noise_area.png

	convert cameraman_idealdefocus15_noise.png[10x50+240+40] -format "%[standard_deviation]" info:
	372.646

	convert cameraman_idealdefocus15_noise.png -format "%[standard_deviation]" info:
	16558.5

	convert xc: -format "%[fx:(372.646/16558.5)^2]" info:
	0.000506467
[IM Output]

So we again deblur using n=0.0005 and also n=0.005 and n=0.00005 for comparison. The jinc function filter image is not explicity supplied, but is created internally. We simply display it here for reference.


	cameradeblur -t defocus -a 15 -m fast -n 0.0005 cameraman_idealdefocus15_noise.png \
[IM Output] [IM Output] ==> [IM Output] [IM Output] [IM Output]

Determining The Blurring Parameters Using The Cepstrum

So far we have generated artificial examples where we knew exactly the type of blur as either motion blur or defocus and the amount and orientation of the blurring. But what if we don't know any of this. What can we do?

If we are lucky and the type of blurring is due to motion blur or defocus, then one can extract the type, amount and orientation of the blurring from something called the Cepstrum image. For defocus, the image will contain a white annular ring in the center of the image whose radius is equal to the diameter of the defocus. For motion blur, the image will contain an array of white dots at the orientation of the motion blur. The center most dots, one on either side of the center of the image will be separated from the origin by a distance equal to the amount of motion blur (or the distance between them will be twice the amount of motion blur). Of course there will also be noise in the image that may obscure the dots, especially if the original image is grayscale.

The cepstrum is generate by first computing a running average of the magnitude of the Fourier Transform from a large set of subsections of the image each of which is windowed using typically about a 40% cosine-bell rolloff to black. The windowing is done to help assure that each subsection conforms to the Fourier Transform assumption that the image is periodic. We take the average result from many subsections to reduce the 'noise' from the image signal and emphasise the effects from the blurring, since the blurring will be the same in each subsection, but the image content will not. The negative log is applied to this running average, which is then stretched to span the full dynamic range. We use a form of the log that has a scaling constant built in. The log is used to emphasize small values more and de-emphasize large values. An appropriate choice of this constant is helpful in reducing the 'noise' from the image signal versus the effect from the blurring. Finally, this result is treated as the real component and combined with a black image for the imaginary component and inverse transformed back to the spatial domain. The name cepstrum is derived from the word spectrum, but with the first four letters reversed. It is in some sense an inverse spectrum, because we create the spectrum (i.e. log of the magnitude), but inverse transform it back to the spatial domain. NOTE that this process requires the use of the real and imaginary components of the Fourier Transform therefore must be done with ImageMagick compiled with HDRI enabled.

Let's do this on the 15 pixel diameter ideal defocused image that we created earlier. The image is 256x256 in size. We will use subsections that are 25% in size (64x64) with a 50% overlap (i.e. offset of 32x32) and a 40% windowing rolloff (i.e. 25.6x25.6). The windowing image will be created and shown next to the defocused image. Once we create the cepstrum image, a red circle of radius 15 relative to the center will be drawn on it.


	convert \( -size 64x1 xc: \
		-fx "(0.5*cos(pi*max(0,(1-i/25.6)))+0.5)*(0.5*cos(pi*max(0,(1-(w-i)/25.6)))+0.5)" -scale 64x64\! \) \
		\( -size 1x64 xc: \
		-fx "(0.5*cos(pi*max(0,(1-j/25.6)))+0.5)*(0.5*cos(pi*max(0,(1-(h-j)/25.6)))+0.5)" -scale 64x64\! \) \
		-compose multiply -composite cos_bell64.png

	convert -size 64x64 xc:black magave.pfm
	k=1
	dh=0
	for ((i=0;i<=192;i+=32)); do
		dw=0
		for ((j=0;j<=192;j+=32)); do
			echo "Iteration: $k"
			pct=`convert xc: -format "%[fx:100/($k)]" info:`
			convert cameraman_idealdefocus15.png[64x64+${dw}+${dh}] cos_bell64.png \
			-compose multiply -composite -fft -delete 1 magave.pfm \
			+swap -compose blend -set option:compose:args $pct -composite magave.pfm
			#echo "i=$i; j=$j; k=$k; pct=$pct"
			dw=$(($dw+32))
			((k++))
		done
		dh=$(($dh+32))
	done
	convert magave.pfm -evaluate log 20000 -negate \
		\( -size 64x64 xc:black \) +ift -roll -32-32 \

	convert -delay 100 cameraman_idealdefocus15_cepstrum_20000.png \
		\( -clone 0 -fill none -stroke red -draw "circle 32,32 32,46" -alpha off \) -loop 0 \
[IM Output] [IM Output] ==> [IM Output]

A script version, cepstrum, is available and its use to create the same pre-animation result as above is as follows. The windowing image does not have to be pre-generated as it is created internally in the script.


	cepstrum -c 20000 cameraman_idealdefocus15.png cameraman_idealdefocus15_cepstrum_20000.png

	convert -delay 100 cameraman_idealdefocus15_cepstrum_20000.png \
		\( -clone 0 -fill none -stroke red -draw "circle 32,32 32,46" -alpha off \) -loop 0 \

Now let's do the same with motion blur, but let's create a motion blur of length 15, but at a -45 degree angle. The same windowing image will be shown next to the motion blurred image, but it is not actually a script input, as it is created internally to the script. Once we create the cepstrum image, a red line of length 30 will be drawn centered on the image at an angle of -45 degrees.


	length=15
	angle=-45
	sinang=`convert xc: -format "%[fx:sin($angle*pi/180)]" info:`
	cosang=`convert xc: -format "%[fx:cos($angle*pi/180)]" info:`
	xfact=`convert xc: -format "%[fx:$cosang*256/2]" info:`
	yfact=`convert xc: -format "%[fx:$sinang*256/2]" info:`
	freq1=`convert xc: -format "%[fx:$length*pi/256]" info:`
	freq2=`convert xc: -format "%[fx:$freq1/(2*pi)]" info:`
	convert \( -size 256x257 gradient: \
		-gravity center -crop 256x256+0+1 +repage \
		-linear-stretch 1x0 -function polynomial "2,-1" \) \
		\( -clone 0 -rotate 90 -evaluate multiply $xfact \) \
		\( -clone 0 -rotate 180 -evaluate multiply $yfact \) \
		\( -clone 1 -clone 2 -compose plus -composite \) \
		\( -clone 3 -function sinusoid "$freq2,0,1,0" -clone 3 +swap -compose divide -composite \
		-linear-stretch 0x1 -fill white -opaque black -write sincfilter15r45.pfm \) \
		\( -clone 4 -clone 4 -compose multiply -composite -evaluate pow 0.5 \) \
		-delete 0-4 -evaluate log 100 sincfilter15r45_abs_log100.png

	convert \( cameraman.png +fft \) \
		\( -clone 0 sincfilter15r45.pfm -compose multiply -composite \) \
		\( -clone 1 sincfilter15r45.pfm -compose multiply -composite \) \
		-delete 0,1 +ift cameraman_idealmotion15r45.png

	cepstrum -c 5000 cameraman_idealmotion15r45.png cameraman_idealmotion15r45_cepstrum_5000.png

	convert -delay 100 cameraman_idealmotion15r45_cepstrum_5000.png \
		\( -clone 0 -fill none -stroke red -draw "line 21.4,42.6 42.6,21.4" -alpha off \) -loop 0 \
[IM Output] [IM Output] ==> [IM Output]

Deblurring Real World Images

In practice, deblurring images with actual real world degradations is generally much harder than those artificially degraded by ideal motion blur or ideal defocus. With real world situations and actual cameras, the degradations do not ideally conform to simple uniform linear motion blur or lens defocus. For example, most motion blur is not uniform and not linear. It does not conform to an ideal or pure straight line spatial filter (or sinc function in the frequency domain). Likewise, most lens defocus does not conform ideally to an ideal or perfect circular disk as the spatial filter (or jinc function in the frequency domain. Furthermore there are other degradations that might be included, which are not uniform over the image, such as depth of field blurring.

Sometimes one may be successful with defocus, if the cepstrum shows a good circular ring. For example, the following is an actual image (subsection) taken with the lens purposely defocused. Image curtesy of Maxim Usatov.

[IM Output]

The following is the result of running the cepstrum script followed by -contrasts-stretch 0x1% and then a 9 pixel radius circle drawn about the center of the image to match the ring of circular dots indicative of the diameter of the defocus.

[IM Output]

To get the appropriate noise constant, we measure the square of the standard deviation in a flat region of the image divided by the square of the standard deviation of the whole image. This concept is shown in the following image and results in a noise constant value estimate of 0.005.
[IM Output]

Then we use the cameradeblur script with -t defocus -d 9 -n 0.005 to recover the image.
[IM Output]

On the other hand, true motion blur is almost never a simple situation that conforms to the ideal models above.

Processing of real (as opposed to ideally blurred images) is very hard. If the degradation is known or can be identified either in the spatial domain (as the point spread function or PSF) or in the frequency domain (as the modulation transfer function or MTF), then it can be used to deconvolve the image. Much study has been reported in the literature on efforts to identify and use this information. However, the techniques for obtaining such information are difficult and the restorations are generally complicated and time consuming.

Another technique is called blind deconvolution. It makes only a few assumptions about the degradation. The solutions are often iterative, updating an estimate for the degradation and then deconvolving the image. Then using that result to improve the estimate for the degradation, etc. One such technique is the Richardson-Lucy technique, which is popular for deblurring astronomical photography. Another technique that is not iterative was first described by Jae S. Lim, Two-Dimensional Signal and Image Processing, Prentice-Hall, 1990. Section 9.3.2, "Algorithms for Blind Deconvolution" and summarized in a lecture by Harvey Rhody. A variation on that theme was later developed as the Quarktet Tria - SeDDaRA Method. One point about these latter two techniques is that they cannot properly handle motion blur or defocus, because they make an assumption that the degradation is positive only. Both motion blur and defocus do not satisfy that assumption, because they obey a sinc and jinc function, respectively, in the frequency domain and therefore contain negative lobes. However, they do a nice job of removing many other types of degradations and so can make significant improvement in real-world degraded images. Another interesting point about these latter techniques is that they can use a similar, but unblurred image to help restore the blurred image.

Template Matching By Normalized Cross Correlation

In this section, we discuss the template matching or the matching of a small image within a larger image to see where the small image best matches to the same size subsection of the larger image. The technique that we use is called Normalized Cross Correlation.

The cross correlation of two equal sized image, is basically the point-by-point multiplication of values within each image, totalling the products.

If the two images are not the same size, then the smaller image is moved across the larger image and the cross correlation is computed for each shift by one pixel and stored in resulting image whose origin represents the smaller image located at the top left corner of the larger image.

The problem with this technique is that the two images may have similar features at least at one shift position of the smaller image relative to the larger image. However, the exposure differences between the two images may make the match values too poor and in fact lead to false matches.

Consequently, we normalize the two image in two ways. First we subtract the mean value of the template image from each pixel value in the template and also subtract the mean value of each subsection of the larger image before doing the correlation operation. Second we divide the template image by its standard deviation and also divide each subsection of the larger image by its standard deviation. The result of this is a normalized cross correlation surface image, which varies from -1 to +1 at best, where +1 corresponds to a perfect match.

In general, we can truncate the correlation surface to only keep non-negative values as anti-correlation is not generally relevant in image matching.

The formula for the discrete normalized cross correlation surface (i.e. from matching digital images) can be expressed as follows.

(19) [IM Output]

Here, C(h,k) is the normalized cross correlation value at each shift position (h,k) of the smaller image's upper left corner relative the larger images upper left corner. The values MS and ML are the mean value of the small image and the mean value of the subsection of the larger image for the current shift position. Likewise, σS and σL are the standard deviations of the smaller image and the standard deviation of the subsections of the larger image at shift position (h,k). The mean and standard deviations introduce the normalization of the images during the cross correlation process. The value N is the total number of pixels contained in the smaller image.

Now, the standard deviation is just the square root of the variance. And computationally, the variance of an image can be computed as the (average of the square of the image) minus the (square of the average of the image). Thus, the standard deviation of the subsection of the large image can be expressed as:

(20) [IM Output]

Therefore, the normalized cross correlation becomes:

(21) [IM Output]

The problem with doing the normalized cross correlation in the spatial domain as defined by the above equation is that it is a very slow process. Correlation in the spatial domain is very similar to convolution. However, in the case of convolution, we generally use small kernels or filter images. Consequently this can be done in a reasonable amount of time. As the small kernel or in this case the small image attains any reasonable size, this process slows down as the square of the small image size.

Consequently, it is more efficient to convert this equation to its frequency domain equivalent and pay the time price of a Fourier Transform on both the small and large images, but be able to do correlation much faster, because correlation much like convolution in the frequency domain is simply a multiply. Thus the time to do the processing increases approximately linearly with the size of the larger image and is mostly independent of the size of the smaller image.

Therefore, the following equation is presented without derivation as the frequency domain equivalent. We introduce a special shorthand notation, an X inscribed inside a circle, , to represent the Forward Fourier Transform of two images, correlation of the two transformed images and finally the Inverse Fourier Transform of the correlation product. For example, A B = I[F*(A) x F(B)]. More specifically this means take the Forward Fourier Transform of A and B. Then convert F(A) to its complex conjugate, F*(A). Then do complex multiplication between F*(A) and F(B) using the real and imaginary components. Then finally take the Inverse Fourier Transform of the product. Using this short-hand notation, the equation for the normalize cross correlation surface or image, becomes:

(22) [IM Output]

In order to multiply two images in the frequency domain, they must be the same size. Therefore we pad the smaller image with zeroes (black) to fill it out to the same size as the larger image. The padding is on the right and bottom. Thus, S is the smaller image padded to the same size as the larger image. L is the larger image and L2 is the square of the larger image, i.e, multiplied by itself. U is a unit image (values=1) the size of the original smaller image, but again padded with zeroes (black). This image is a windowing image that is used to select every possible section of the L image that is the size of the smaller (unpadded image). MS is an image the size of the smaller image, whose constant value is equal to the mean value of the smaller image, but again it is padded with black. In effect, S-MS is just the smaller image with its mean subtracted and the difference is padded with black. Note, however, that it will have both positive and negative values. But we can do that in HDRI ImageMagick with a proper choice of image format that permits negative values. Here again N is the total number of pixels in the original (unpadded) smaller image and σS is the standard deviation of the original (unpadded) smaller image.

In practice, we convert the two images to grayscale to do the normalized cross correlation to avoid any possibility of getting different matching locations from each channel.

Two examples will be presented. Each is produced by the script, normcrosscorr. The script is presented here rather than an extremely long set of command line operations, because the implementation requires 3 repetitions of complex multiply, each of which is accomplished with a long set of -composite with a -compose operations.

Under ordinary circumstances, the above equation should normalize to a range between -1 and +1. A perfect match would then become +1. ImageMagick is a bit strange in that it normalizes the values in each image to a range of 0 to 1, internally, before doing any operation such as image-to-image multiplication. The above formulae are founded upon proper multiplication of the un-normalized FFT (and normalized IFT) images. The result is that with Imagemagick, one has to account for scaling of multiplied images by quantumrange, scaling the square root by dividing by sqrt(quantumrange) and also account for correction for the type of FFT normalization by multiplying the two paddedimages, U and (S-Ms) by the total pixels of the large image, if normalization is in the forward FFT rather than the inverse IFT. Due to Imagemagick's internal normalization of images to the range 0 to 1, the U image is actually a fully white region the size of the smaller image (rather than a unit image), but padded with black to the size of the larger image.

See Fourier Transform Normlization for a list of various FFT vs IFT normalizations.

In the first example, the smaller image is just a 64x64 pixel subsection of the larger 128x128 imagee. The subsection was created with its upper left corner coordinates at (32,27) in the larger image. A 3D plot of the stretched correlation surface is also shown.


	normcrosscorr zelda3_32_27.png zelda3.png zelda3_ncc.png zelda3_match.png
	Match Coords: (32,27) And Score In Range 0 to 1: (0.999681)

[IM Output] [IM Output] ==> [IM Output] [IM Output] [IM Output]

The -s option tells the script to stretch the correlation surface to full dynamic range before output. The result shows that the correct match was indeed found, and the match score was 0.665. This is the largest value in the correlation surface image and it corresponds to the location of the top left corner of the smaller image at the best match locatation in the larger image.

In the second example, the smaller image is a 23x14 subsection of the larger 256x256 image. It corresponds to the eye of the mandril on the right side of the image. The subsection was created with its upper left corner coordinates at (156,22) in the larger image.


	normcrosscorr -c white mandril3_156_22.png mandril3.png mandril3_ncc.png mandril3_match.png
	Match Coords: (156,22) And Score In Range 0 to 1: (0.998915)

[IM Output] [IM Output] ==> [IM Output] [IM Output]

The -p argument tells the script to pseudocolor the correlation surface rather than leave it grayscale. Low values are purple and high values are red. The -c argument tells the script to draw the box representing the match location of the smaller image in the larger image in the desired color, in this case white. The result again shows that the correct match, the right eye, was indeed found, and the match score was 0.276.

However, one can see that the left eye also has a high score by its coloration in the correlation surface. The selection of the small eye image was done purposely to show such a case. So how can we determing the value at this second peak in the correlation surface, since the script only gives us the highest score. Furthermore, the area around the right eye is also a close match.

We can process the stretched correlation surface by subtracting the local mean value in a 3x3 neighborhood from the each pixel and threshold that at an appropriate level to separate out the two highest values in the surface. This difference is like an edge or slope extraction. The difference will be positive where the image is higher than the mean and negative where the image is lower than the mean. Since the peaks are very sharp near the eyes, there will be a large slope there and an appropriate threshold should then be able to locate just those two peak values. Once we get the two highest values we can then draw boxes the size of the smaller image within the larger image for where those two matches occur. A 3D plot of the stretched correlation surface is also shown.


	convert mandril3_ncc.png  \
		\( -clone 0 -convolve '1,1,1,1,1,1,1,1' \) \
		\( -clone 0 -clone 1 +swap -compose minus -composite \) \
		-delete 0,1 -threshold 15% txt:- | grep white | \
		tail -n +2
	156,22: (65535,65535,65535)  #FFFFFFFFFFFF  white
	76,24: (65535,65535,65535)  #FFFFFFFFFFFF  white

	convert mandril3.png -fill none -stroke white \
		-draw "rectangle 156,22 178,35 rectangle 76,24 98,37" -alpha off mandril3_match2.png
[IM Output] ==> [IM Output] [IM Output]

A more flexible method is to locate the first peak, then mask it out, locate the next highest peak and mask it out, etc. I have a new script called maxima that will do just that.

	maxima -n 2 mandril3_ncc.png
	156,22 gray=65535,255,100%
	76,24 gray=54453,212,83.09%

Fast Template Matching Using Local Statistics In The Fourier Domain

The following link is to my unpublished paper describing the mathematical basis for various types of correlation-based template matching computed fully via Fourier Transforms, which are 1 to 2 orders of magnitude faster than doing the same in the spatial domain. ACCELERATED TEMPLATE MATCHING USING LOCAL STATISTICS AND FOURIER TRANSFORMS.pdf


My thanks to Sean Burke for his coding of the original demo and to ImageMagick's creator for integrating it into ImageMagick. Both were heroic efforts.
